Pneumatic fabric dilatometer
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Application
It is mainly used to test the bursting strength and bursting expansion of knitted fabrics, woven fabrics, non-woven fabrics, laminated fabrics, and other fabrics manufactured by various processes under standard conditions or in a wet state.
Standard Test
ISO 13938.1：Textiles - Bursting properties - Part 1: Hydraulic method for determination of bursting strength and bursting distension
ASTM D 3786：Standard Test Method for Bursting Strength of Textile Fabrics by Hydraulic Pressure
JIS L1018.6.17：Textiles - Testing methods for woven fabrics - Part 6: Bursting strength
FZ/T 60019: Nonwoven fabrics - Determination of bursting strength
FZ/T 01030: Determination of seam strength and elongation of knitted fabrics and elastic woven fabrics - Grab method
GB/T 7742.1-2005: Textiles - Bursting properties - Part 1: Determination of bursting strength and bursting distension - Hydraulic method
Feature
Strong after-sales service team
Timely and efficient problem resolution for customer peace of mind
Complete spare parts inventory to avoid long waiting times
Regular updates to meet the latest industry standards
Parameters
| Bursting Strength Range | 0 ~ 3000 kPa |
| Bursting Expansion Range | Typically several tens of millimeters |
| Test Area | Common areas: 50 cm² (Ø79.8 mm), 100 cm² (Ø112.8 mm) Customizable based on standards and testing requirements |
| Sample Clamping | Pneumatic clamping system |
| Bursting Time | Typically 20 ± 5 seconds (adjustable) |
| Accuracy | ±2% of full scale ±1 mm displacement |
