Thermal Radiation Performance Tester(RPP)
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The RPP test is mainly used to determine the radiant thermal protection performance of thermal protective clothing. Since thermal radiation is one of the main heat transfer forms that cause thermal damage. The method can better test and evaluate the thermal protection performance of thermal protective clothing from one aspect, and has been widely used in the field of forest fire.
Standards：
NFPA 1971. NFPA 2112. BS EN ISO 6942. EN 366. ASTM F2702. ASTM F1939
Features：
◆Evaluation of flame retardant properties of flame retardant materials
◆Detect abnormalities and reduce accidents
◆Calculate the RPP value
◆Evaluate thermal protection performance
◆Improve job safety
◆Improve the quality control system
Technical Parameters：
| Items | Parameters |
| Heating power | 6.5Kw/220V/50Hz |
| Heating length | 178mm, diameter 8mm |
| Heat flux density | 10Kw/m2-80Kw/m2 |
| Radiation source temperature control | －1200℃±5℃ |
| Thermal radiation source temperature sensor | Thermocouple (0 ℃ -1600 ℃) |
| Calorimeter heat capacity | 480.937J/K |
| Heating area | 50mm2×50mm2 |
| Calorimeter temperature range | －80℃ |
| Test environment |
Between 15 ℃ -35 ℃ ,the room without air circulation |
