Fabric Static Tensile Tester
Application
Suitable for woven, knitted, and nonwoven fabrics, the tester is ideal for quality control, research, and certification of textiles in apparel, home textiles, industrial fabrics, and technical textiles. Its multi-station setup allows simultaneous testing of multiple samples, increasing efficiency and consistency in laboratory environments.
Standards
ASTM D3107: Standard Test Method for Tensile Properties of Fabrics
ISO 13934-1: Tensile properties of fabrics—Determination of maximum force and elongation at maximum force
BS EN 14704-1: Textiles—Tensile testing methods for fabrics
GB/T 3923.1: Determination of tensile properties of fabrics
Feature
Multi-station design allows testing of six samples simultaneously, improving laboratory efficiency.
Stainless steel construction ensures durability and corrosion resistance.
Manual clamping mechanism provides secure sample fixation with zero looseness.
High-precision measurement minimizes human error in elongation determination.
Compact benchtop design with integrated weight box allows easy relocation.
Overload protection and ergonomic handles enhance operator safety and comfort.
Optional software integration enables real-time force-displacement curve analysis.
Parameters
| Parameter | Specification |
|---|---|
| Number of stations | 6 |
| Maximum force per station | 50 N (customizable) |
| Sample clamping | Manual, stainless steel fixtures |
| Measurement method | Dimensional mark tracking for elongation |
| Dimensions | 600 × 400 × 500 mm (approx.) |
| Power supply | AC 220V, 50Hz |
| Weight | 75 kg (approx.) |
