Textile formaldehyde content tester

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

Application

This tester is widely used in:

Textile manufacturing and processing factories for quality control.

Garment production lines to ensure finished products meet formaldehyde safety standards.

Textile laboratories for research and development of safe, low-formaldehyde fabrics.

Inspection and testing agencies verifying compliance with regulatory standards.

Educational institutions for textile chemistry and safety training.

Standards

The instrument is compliant with:

GB/T 2912 – Textiles: Determination of formaldehyde – Part 1: Free and hydrolyzed formaldehyde

AATCC 112 – Textiles: Determination of formaldehyde – Vapor absorption method

BS 6806 – Textile formaldehyde testing

DIN EN ISO 14184-2 – Textiles: Determination of formaldehyde – Part 2: Released formaldehyde (vapor absorption method)

Relevant Chinese national standards: GB 18401-2003, GB/T 23328-2009, GB/T 2664-2009, GB/T 2665-2009, GB/T 2666-2009, GB/T 23314-2009

Features

(1) Large 128×64 dot-matrix LCD display for clear and accurate readings.

(2) Continuous testing with storage of up to 200 data sets; each screen displays 5 sets.

(3) Supports C mode (multi-point standard curve method) and F mode (coefficient method) for flexible analysis.

(4) Power-off memory ensures stored data and standard curves are preserved.

(5) Automatic wavelength calibration, deviation self-repair, and automated settings.

(6) Dual light sources: deuterium lamp and long-life tungsten lamp for UV and visible spectrum.

(7) Standard USB data output interface and parallel print output for easy reporting and integration.

(8) Quantitative analysis software included for direct photometric analysis and data processing.

Parameters

ParameterSpecification
Wavelength Range 190–1000 nm
Spectral Bandwidth 4 nm or 2 nm optional
Wavelength Accuracy ±1 nm
Wavelength Repeatability ≤0.3 nm
Wavelength Setting Automatic
Wavelength Resolution 0.1 nm
Luminosity Accuracy ±0.5% T
Photometric Repeatability ≤0.2% T
Stray Light ≤0.05% T
Data Output USB interface
Stability ±0.001 A/h (at 500 nm after preheating)
Luminosity Range 0–200% T, -0.3–3A, 0–9999C
Print Output Parallel port
Display System 128×64 bit LCD
Light Source Imported long-life tungsten lamp & deuterium lamp
Detector Imported silicon photodiode
