Fabric horizontal burning tester
The horizontal flammability tester is a device used to evaluate the combustion performance of materials. It simulates the effect of a flame on a sample in a horizontal direction, observing and recording the combustion phenomena, and measuring key parameters such as the burning rate, flame spread time, and flame retardant properties of the material. This device is widely used in fields such as textiles, plastics, and building materials, and is an important tool for product quality control and safety assessment.
Applications
Widely used in textiles, plastic products, building materials, and other fields.
Suitable for various stages including product quality control, safety assessment, and research and development testing.
Standard
QB/T 2729: Leather – Horizontal flammability test for physical and mechanical properties.
ASTM D5132: Horizontal burning rate of polymeric materials in vehicle occupant compartments.
SAE J369: Polymeric interior material flammability – Horizontal test method.
FMVSS 302: Flame retardancy of automotive interior materials (cars, trucks, buses).
ISO 3795: Burning behavior of interior materials in road vehicles and agricultural machinery.
DIN 75200: Combustion performance of automotive internal equipment materials.
ISO/NP 17074: Leather – Determination of horizontal flame spread resistance.
Product Advantages
Precision & Repeatability: Delivers highly repeatable experimental data to evaluate material flame-retardant performance accurately.
Broad Applicability: Tests leather, polymers, textiles, and automotive interior parts (e.g., seats, roof linings, curtains).
Safety-First Design: Electrical control and combustion chamber are separated to prevent fire hazards, ensuring stable operation.
Automated Data Capture: Precisely records ignition time and flame spread duration for objective analysis.
Compliance Assurance: Meets stringent automotive and textile industry standards, simplifying export certifications.
Research & Development Support: Provides critical data for new material development and quality control.
Features
Dual-Chamber Structure: Isolated electrical control unit and combustion chamber enhance safety and operational stability.
Multi-Material Testing: Suitable for automotive interiors, public transport components, and industrial textiles.
Adjustable Ignition System: Angled burner (0° or 45°) with precise燃气pressure control (0-50kPa).
High-Precision Measurement: Accurately tracks flame spread distance and time (resolution: 0.1s).
User-Friendly Interface: Digital display for real-time monitoring and data storage.
Compliance-Driven: Aligns with ASTM, ISO, SAE, and DIN standards for global market access.
Parameters
| Parameter | Specification |
|---|---|
| Ventilation Slot Height | 13 mm |
| Vent Hole (Bottom) | Diameter φ19 mm × Depth 10 mm |
| Observation Window Width | 330 mm |
| Sample Rack Dimensions | 255 mm × 200 mm × 170 mm (L×W×H) |
| Sample Fixture | U-Type, 355 × 25 × 10 mm (Inside Margin: 50 mm) |
| Flame Box Dimensions | 368 mm × 216 mm × 356 mm (L×W×H) |
| Burn Timer | Accuracy: ±0.1 s |
| Standard Flame Height | 38 mm |
| Collection Plate | 55 mm × 119 mm × 19 mm |
| Ignition Time | 15 s (Adjustable) |
| Overall Dimensions | 390 mm × 200 mm × 390 mm (L×W×H) |
| Support Wire | φ0.25 mm (High-Temperature Resistant Wire) |
| Spading | 25 mm |
| Weight | 31 kg |
| Power Supply | AC 220V ±10%, 50Hz |
