Walk In Pharmaceutical Stability Chamber
Get a quote:
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Pharmaceutical Stability Testing Laboratory is designed for conducting accelerated humidity and heat testing, long-term stability testing, and constant humidity and heat testing on pharmaceutical intermediates, active pharmaceutical ingredients, finished pharmaceutical products, and medical devices. It also supports cultivation of plant and animal samples and bacterial cultures, as well as low-temperature storage, enabling analysis and evaluation of product behavior. This facility serves dedicated research in pharmaceuticals, medicine, biotechnology, food processing, electronics, and all life science-related industries.
Parameters
| Item | Specification |
|---|---|
| Test Area Dimension | Specific dimensions to be designated by the customer based on usage conditions! |
| External Dimension | Subject to the quotation plan |
| Operating Temperature Range | SBY: 0°C ~ +60°C |
| Relative Humidity Range | 30% ~ 95% RH |
| Temperature Deviation | ≤±2°C (≤1°C for incubation chambers) |
| Humidity Deviation | ±5% RH |
| Temperature Fluctuation | ≤±0.5°C |
| Heating Time | ≤30 min |
| Cooling Time | 30 min ~ 180 min (varies by model) |
| Material | Exterior: A3 color steel plate + spray coating; Interior: SUS#304 stainless steel; Insulation layer: PU foam |
| Temperature & Humidity Control System | Imported fully-hermetic or semi-hermetic compressor from Europe, America, Japan, or Korea; Refrigerant: R134a; Axial flow fan with side/top air outlet; High-performance heater; Steam humidification; ADP critical point condensation dehumidification; Air-cooled or water-cooled options |
| Controller | Adopt Yonghe's own brand or Korean TH500/TH300 touch screen controller; Display precision: Temperature 0.1°C, Humidity 0.1% RH; Operation modes: Program mode, fixed value mode; Control method: Microcomputer PID with integral operation; Input signal: PT100 platinum resistance |
| Observation Window | Multi-layer hollow anti-fog explosion-proof glass |
| Safety Devices | Over-temperature protection, leakage protection, water shortage protection, humidification system protection, compressor over-pressure/overload/over-current protection, fan overload protection, phase sequence protection |
| Power Supply | AC380V (1±10%) V, 50±0.5 Hz, 3-phase 4-wire + protective earth |
| Optional Accessories | Temperature & humidity recorder (capable of simultaneous recording of temperature/humidity signals and multiple test points), large observation window, test hole, SMS alarm, high/low temperature deviation alarm, dual-compressor system, etc. |
| Extendable Products | Constant temperature incubation chamber, constant temperature & humidity test chamber, high-low temperature test chamber, constant temperature room, aging test chamber, burnout test chamber, etc. |
| Special Notes | Customizable dimensions available to meet customer requirements |
