Shoes Thermal Insulation Tester
Get a quote:
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Shoe Sole Heat Resistance Tester is designed to evaluate the thermal insulation and heat resistance performance of finished footwear soles. By simulating exposure to high-temperature surfaces using sand or steel balls as a heat medium, the tester provides objective measurements of temperature rise at the insole, ensuring the footwear meets safety requirements for hot environments.
Standards
(1)EN ISO 20344 — Personal Protective Equipment — Footwear — Test Methods
(2)EN ISO 8782-1 — Footwear — Evaluation of Heat Resistance
(3)GB/T 20991-2007 — Footwear Test Methods
(4)ANSI — American National Standards for Footwear Safety
(5)JIS — Japanese Industrial Standards for Footwear
(6)CSA — Canadian Standards Association Footwear Standards
(7)GB 12017-1989 — Safety Footwear Heat Resistance Test
(8)LD50-1994 — Footwear Heat Resistance Evaluation
Technical Parameters
| Item | Specification |
|---|---|
| Sand Bath Box Size | 40 ± 2 cm × 40 ± 2 cm, height 8 cm |
| Sand Height | ≥5 cm |
| Sand Particle Size | 0.3 – 1.0 mm |
| Sand Volume | 5000 ± 250 cm³ |
| Test Temperature | 150 ± 5℃ or 250 ± 5℃ |
| Heating Power | ≥2500 ± 250 W |
| Heat Transfer Medium | 5 mm steel balls, total mass 4 kg |
| Temperature Measurement | Copper/copper-nickel thermocouple with copper disc, 2 ± 0.1 mm thick, 15 ± 1 mm diameter |
| Test Duration | 30 minutes |
| Accuracy | ±0.5℃ |
| Power Supply | AC 220V |
