Backsheet Scratch Resistance Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Backsheet Scratch Resistance Tester evaluates the scratch resistance of photovoltaic (PV) module backsheets. By applying a standardized sharp edge with controllable speed across the module backsheet surface, it simulates scratches that may occur during transportation, installation, or daily use.
Standards
IEC 61730-2 – Photovoltaic (PV) Module Safety and Mechanical Performance
UL 1703 – Standard for Safety of Photovoltaic Modules
Parameters
| Item | Technical Parameter |
|---|---|
| Workbench Material | Aluminum alloy |
| Workbench Size | 1.4 m × 0.65 m |
| Traction Pulley | Integrated, for smooth carriage movement |
| Carriage Saw Blade Material | Carbon steel |
| Saw Blade Thickness | 0.64 mm ± 0.05 mm |
| Blade Tip Radius | 0.115 ± 0.025 mm |
| Saw Blade Adjustability | Distance and angle adjustable to meet standards |
| Weights | Standard weight box, 8.9 N ± 0.5 N |
| Traction Method | Motorized constant-speed, continuously adjustable |
| Traction Direction | Adjustable |
| Scratch Speed | 150 ± 30 mm/s |
