Leather Water Vapor Permeability Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Leather Water Vapor Permeability Tester measures the ability of leather and leather-like materials to transmit water vapor. By assessing the weight of water vapor that passes through the material per unit area and time, it evaluates the breathability and moisture transport performance of leathers, textiles, and composite materials. The instrument is equipped with multiple test stations, controlled ventilation, and precise timing for standardized laboratory measurements.
Standards
(1) UNI EN IUP/15 – Italian standard for testing puncture resistance of safety footwear.
(2) UNI EN 13515 – European standard specifying abrasion resistance tests for protective footwear soles.
(3) EN ISO 20344:6.6 – International standard defining puncture resistance testing methods for safety shoes.
(4) IUP 15 – Standard for evaluating puncture-resistant properties of footwear materials.
(5) BS 3144 Method 24 – British standard for abrasion resistance testing of leather and footwear components.
(6) SLP 25 – Standard protocol for assessing safety shoe durability under repetitive stress.
(7) DIN 53333 – German standard for puncture resistance measurements in protective footwear.
(8) ISO 17699 – International standard for footwear safety, including puncture and impact resistance.
(9) DIN 53 429 – German method for abrasion resistance testing of rubber and plastics in footwear.
(10) METODO - 309 WI 009 – Brazilian standard for puncture resistance evaluation in safety footwear.
Parameters
| Parameter | Specification |
|---|---|
| Test Stations | 6 |
| Electronic Timer | Built-in, records test duration |
| Fan Blades | 3 |
| Fan Blade Dimensions | 75 × 90 mm |
| Angle Between Fan Blades | 120° |
| Fan Gaps | 10 ± 5 mm |
| Fan Speed | 1400 rpm |
| Specimen Rotary Speed | 75 rpm |
| Sample Holder Diameter | 30 ± 1 mm |
| Fixture Diameter | 30 ± 1 mm, helical |
| Instrument Weight | 45 kg |
| Overall Dimension | 350 × 570 × 450 mm |
| Power Consumption | 300 W |
