Xenon Arc Weather Ometer SI4000
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
SI4000Xenon Arc Weather Ometer utilizes a xenon lamp to simulate ideal natural climate and sunlight conditions. It is suitable for suitable for aging tests of various industries and products, and can accurately measure the lifetime of products., including textiles, wire and cable, plastics, coatings, and building materials. Its exceptionally cost-effective performance rivals the industry's CI series weathering chambers, enabling precise testing of product lifespan while ensuring excellent repeatability and reproducibility.
The SI4000 Xenon Arc Weathering Tester complies with nearly all major international, national, and industry test standards, including ASTM, ISO, SAE, AATCC, IEC, and GB. The following is only a partial list. For more information and a more precise list of compliance standards, please contact a sales representative.
Technical Parameters:
| Category | Parameter | Technical Data | Remarks |
| General Information | Operation Mode | Automatic | |
| Light Source | 6500 W water-cooled xenon lamp | ||
| Lamp Life | 2000 hours | ||
| Filters | Interchangeable internal and external filters | ||
| Irradiance Control | Spectrum Range | 340/420 nm or 300–400 nm | Selectable |
| Control Type | Single-point automatic control | Optional second-point monitoring | |
| Irradiance Stability | Automatic regulation | ||
| Temperature & Humidity Control | Chamber Temperature | 25–100 °C | Automatic control |
| Relative Humidity (Light Cycle) | 10–75 % RH | ||
| Relative Humidity (Dark Cycle) | 10–100 % RH | ||
| Black Panel Temperature (BPT) | 40–110 °C | ||
| Black Standard Temperature (BST) | 40–120 °C | ||
| Simultaneous Control | BPT/BST and chamber temperature control | Dual control optional | |
| Water & Spray System | Pressure | 38–345 kPa (20–50 psi) | |
| Humidification | Deionized water 0.12 L/min | ||
| Specimen Spray | Deionized water 0.07 L/min | ||
| Rack Spray | Deionized water 0.07 L/min | ||
| Specimen Holder | Type | Three-tier | |
| Large Diameter | 648 ± 6 mm | ||
| Small Diameter | 511 ± 6 mm | ||
| Tilt Angle | 28 ± 2° | ||
| Rotation Speed | 1 RPM (adjustable) | ||
| Electrical & Environmental Requirements | Power Supply | 380 V / 220 V, 50 Hz | |
| Maximum HVAC Load | 26.06 MJ/h (≈ 24,703 BTU/h, 275 CFM) | ||
| Air Flow | 0.11 m³/min | ||
| Weight | 550 kg | ||
| Dimensions (W × D × H) | 1400 × 1650 × 2210 mm |
