Small Solar Simulator
Get a quote：
Web: qinsun-lab.com
Email：info@qinsun-lab。com
TheSmall Solar Simulatoris a precision laboratory device designed for the controlled simulation of solar radiation. You can use it to replicate sunlight intensity and spectrum for research and development or production testing of photovoltaic cells, materials, and modules. This simulator enables accurate performance evaluation, material aging tests, and chemical or photocatalytic reaction studies. Its compact design, adjustable irradiance, and stable output make it ideal for laboratory environments requiring reliable and repeatable solar simulation.
Standards
(1) IEC 60904-9 – Photovoltaic Devices: Requirements for Solar Simulators
(2) ASTM E927 – Laboratory Simulation of Solar Radiation
(3) IEC 60904-3 – Measurement of Photovoltaic Current-Voltage Characteristics
(4) ISO 9060 – Solar Irradiance Measurement Standards
(5) ASTM G173 – Reference Solar Spectra for Testing
Technical Parameters
| Performance Item | Specification | Notes |
|---|---|---|
| Spectral Matching | AM1.5G, Class A (≤±10% deviation) | Ensures output spectrum closely replicates sunlight |
| Irradiance | 350–1000 W/m², Adjustable | Supports 0.35–1 sun range for diverse testing |
| Spot Uniformity | ≤±2% | Uniform light distribution across the test plane |
| Light Source Type | Xenon lamp or LED array | LED: longer lifespan (~10,000 hours) and higher stability |
| Operating Mode | Continuous steady-state (CW) | Eliminates transient errors from pulsed sources |
| Illuminated Area | D50mm–D200mm | Customizable based on testing requirements |
| Power Supply | 220 V ±10% AC, 50/60 Hz | Standard laboratory power input |
| Cooling System | Air-cooled | Maintains stable light output and extends lamp lifespan |
| Equipment Dimensions | Approx. 0.6 × 0.4 × 0.5 m | Compact design for laboratory tables |
