TDM Cutting Resistance Tester
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
The TDM straight blade travels once across the test material and is only used once. TDM Test rates materials on a scale of A - F and uses an oscillating blade that measures the force necessary to cut through high-cut materials. Materials that test beyond Level 3 or produce a false Coupe Test reading will receive an "X", and the TDM Test is introduced where a letter rating A - F is determined (Example 4X43FP). If the TDM Test isn't required, an "X" is used to state that there's no rating (Example 4243XP).
Application:
This machine is used for TDM grading test (cutting force N) of gloves, protective clothing fabrics and other fabrics, composite materials, rubber and other materials for cutting resistance.
Standards:
ISO 13997, BS EN 1082-2:5.4, EN 388, GB 24541-2022:6.3, ASTM F2992/F2992M-15, ANSI/ISEA 105-2016:5.1.1
Technical Specifications：
| Vertical Cutting Force Load | 0~100N |
| Horizontal Cutting Force | 25N |
| Total Vertical Stroke Of Sample Rack | 35mm |
| Effective Vertical Stroke Of Sample Rack | 10mm |
| Cutting Speed | 150mm/min@±10% |
| Cutting Stroke | 200mm |
| Test Loading Stand Lever Ratio | 2:01 |
| Cutting Distance Reading Accuracy | 0.01mm, graduation value 0.001mm |
| Annular Combination Weight Specification | 2kg-1mg (ring weight + sheet weight) 1 set |
| Power | 1phase, AC 220V 50Hz 500W |
| Dimension (W×D×H) | 45×45×44cm |
| Weight | Approx 20kg |
