High-End Model of Vacuum Cleaner Dust Removal Performance Testing Equipment
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
TheHigh-End Vacuum Cleaner Dust Removal Performance Testing Equipmentis designed to evaluate the dust removal and cleaning performance of vacuum cleaners on carpets and hard floors. You use this system to simulate real cleaning conditions by driving the vacuum cleaner across standardized test surfaces under controlled speed and stroke settings. Manufactured in compliance with relevant national and international standards, the equipment provides reliable performance data for product development, quality control, and laboratory testing.
Standards
-
GB/T 20291.1-2014: Household and Similar Electrical Appliances – Vacuum Cleaners – Part 1: Methods for Measuring Performance
-
IEC 60312:2010: Vacuum Cleaners for Household Use – Methods for Measuring the Performance
-
IEC 62885-2:2020: Surface Cleaning Appliances – Part 2: Dry Vacuum Cleaners for Household or Similar Use – Methods for Measuring the Performance
Features
-
You can accurately simulate real cleaning motion through synchronized servo-driven movement
-
PLC-controlled operation ensures stable speed, stroke, and test repeatability
-
Automatic dust dispersion improves consistency of dust distribution on test surfaces
-
Supports both carpet and hard floor dust removal performance evaluation
-
Integrated electrical parameter monitoring records voltage, current, power, and energy consumption
-
Touchscreen interface allows intuitive parameter setting and test control
-
USB data export enables convenient result storage and report generation
Technical Parameters
| Item | Specification |
|---|---|
| Particle Size Measurement Range | 0.3 μm – 10 μm |
| Counting Range | < 1 – 1,000,000 particles/cm³ |
| Power Supply | 220V, 50/60 Hz, 1.5KW |
| Filtration Efficiency Calculation Method | Laser particle counter |
| Control System | 17-inch touch screen + industrial computer + Mitsubishi PLC (Japan) |
| Particle Size Counting Method | Upstream + downstream synchronization |
| Dust Generator | Vacuum dispersion technology |
| Test Chamber | 1100×600×1400 mm, with visual observation window; Weight: approx. 170 kg |
| Gas Filtration Technology | High-efficiency filter |
| Equipment Dimensions | 1850×820×2250 mm (W×D×H) |
