Compact Benchtop Friction and Wear Tester
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
The Compact Benchtop Friction and Wear Tester is suitable for a wide range of laboratory and industrial tribology applications, including:
Friction, wear, and scratch performance evaluation of metals, ceramics, polymers, coatings, and composite materials
Surface damage, indentation, and scratch resistance analysis
Fretting and linear reciprocating wear studies
Tribological behavior testing under high-temperature, low-temperature, vacuum, and corrosive conditions
Lubricant and additive performance evaluation using rotational and reciprocating test modes
Supported test configurations include ball-on-disk, pin-on-disk, high-speed reciprocating motion, and ring-on-block testing, with optional integration of 3D optical surface profiling.
Standards
The tester is designed to support test methods referenced in the following standards:
ASTM G99 (Standard Test Method for Wear Testing with a Pin-on-Disk Apparatus)
ISO 20808 (Fine ceramics — Determination of friction and wear characteristics of monolithic ceramics by ball-on-disk method)
GB/T 3142 (Determination of load-carrying capacity of lubricants — Four-ball method)
SH/T 0189 (Test method for anti-wear properties of lubricating oils — Four-ball method)
Parameters
| Item | Description |
|---|---|
| Platform | Open-platform design for easy access and operation |
| Interchangeable Test Modules | Quickly replaceable modules enabling multiple tests on the same platform (rotational, reciprocating, etc.) |
| Force Sensors | High-resolution force sensors with multiple measurement ranges; maximum load up to 200 N |
| XY Stage | High-precision automated XY platform with automatic test radius adjustment; supports integration of 3D optical surface profiling |
| Maximum Temperature | Up to 1000 °C |
| XY Travel Range | 150 mm × 150 mm |
Features
Standard test configurations including ball-on-disk (pin-on-disk) and high-speed reciprocating motion
Loading range from mN up to 200 N, suitable for micro- to macro-scale tribological testing
Integrated 3D optical surface profiling capability
Closed-loop servo loading control for stable and repeatable measurements
High-temperature testing capability up to 1000 °C
Support for rotational, reciprocating, and ring-on-block test modes
Modular design with fast replacement of test modules
Fully automated XY positioning platform (150 mm × 150 mm)
