IEC 63180 Infrared and Microwave Sensing Test Dummy
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
The test dummy is applicable to a wide range of sensing products and scenarios, reflecting mainstream testing requirements and industry-standard protocols:
Infrared motion-sensing lamps (PIR lamps)
Microwave radar motion-sensing lamps
Infrared and microwave hybrid sensing devices
Indoor and outdoor intelligent lighting sensors
Smart security human detection modules
Building automation sensing controllers
Smart home motion-sensing switches and modules
R&D stage performance verification of sensing products
Production consistency testing and type approval
Standards
The system can be used to verify and evaluate compliance with the following standards:
GB/T 17743 – Electromagnetic compatibility of electrical lighting equipment
GB/T 24824 – General technical requirements for infrared detectors (relevant clauses)
IEC 63180 – Performance testing methods for infrared and microwave sensing devices
IEC 60598 – Luminaires; supplementary verification of sensing functions
IEC 62386 – Intelligent control systems; functional verification reference
Product Specifications
Simulated Human Robot
| Item | Technical Specifications |
|---|---|
| Total Height | 1.8 m (including mobile platform) |
| Mobility | Omni-directional four-wheel chassis |
| Moving Speed | 1 m/s |
| Moving Direction | Straight / 45° diagonal |
| Step Distance | 0.5 m / 1 m adjustable |
| Surface Temperature Range | 30 – 40 °C, adjustable |
| Temperature Uniformity | Uniform body surface heating |
| Heated Areas | Head and chest |
| Power Supply | Built-in rechargeable battery |
| Endurance | Capable of full-day continuous testing |
| Control | Remote / software integration |
Elevation & Rotation Platform
| Item | Technical Specifications |
|---|---|
| Elevation Range | 1 – 5 m |
| Elevation Step | 0.5 m |
| Rotation Angle | 0 – 360° |
| Rotation Accuracy | 5° / 10° adjustable |
| Mounting | Wall-mounted / ceiling lamp installation |
| Structure Material | Low-metal content design |
| Mobility | Omni-directional wheeled base |
| Control | Remote / software control |
Product Features
IEC 63180 Standardized Test Configuration: Radial and circumferential measurement points enable comprehensive detection coverage mapping.
Repeatable Human Motion Simulation: Robot movement paths, speed, and pause times are precisely controlled to eliminate human variability.
Realistic Human Thermal Radiation: Head and chest heating simulates human infrared radiation characteristics for PIR testing.
Dual-Mode Infrared & Microwave Platform: Structural design minimizes metal interference while accommodating both IR and microwave measurements.
Modular System Architecture: Robot, elevation/rotation platform, and software can operate independently or in combination, facilitating upgrades and expansion.
