Underwear Pressure Comfort tester

Whats/App: +86 156 1874 6768

Web: standard-groups.com

Application

You use this tester to assess wearing pressure and contact force of garments under simulated human body conditions.

It is suitable for testing knitted tight-fitting garments, underwear, compression clothing, functional sportswear, medical compression garments, and other apparel where wearing pressure and comfort performance are critical.

Standards

The Simulated Human Body Underwear Wearing Force Tester complies with the following standard:

(1) FZ/T 70015-2022 Test and evaluation method for pressure of knitted tight-fitting garments

Parameters

ItemSpecification
Main Sensor Force Range 0–10.000 cN
Main Sensor Accuracy 1%
Micro Sensor Force Range 0.00–200.00 cN
Micro Sensor Accuracy 0.03 cN
Garment Body Shape Control Range 0–50 mm
Power Supply AC 220 V ±10%, 50 Hz
Overall Dimensions (L × W × H) 1446 × 400 × 248 mm
Net Weight 56 kg

Features

You benefit from multi-sensor micro-force detection for high-precision measurement.

The system provides stable and reliable long-term force monitoring during garment wearing tests.

Test data are recorded in both numerical form and multi-color curves for clear analysis.

The intelligent analysis software supports full-process data recording and evaluation.

A PC-based graphical interface offers intuitive operation and clear visualization.

The tester supports functional evaluation, comfort assessment, and health-related research of garments.
