Apparel Drying Dynamics Control System
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
The tester is widely used for:
Quality control of sportswear and moisture-wicking fabrics.
Research and development of quick-dry textiles and performance garments.
Testing waterproof and water-repellent fabrics for drying efficiency.
Forensic textile analysis of fabric degradation due to moisture exposure.
Textile education and training on drying mechanism principles.
Standards
ISO 11092 – Textile evaporative resistance
ASTM D737 – Air permeability and drying correlation
AATCC 195 – Moisture management properties
GB/T 12704-2019 – Chinese textile drying standard
Features
(1) Multi-Test Modes: Static drying, dynamic drying simulating body movement, and rain simulation for waterproof fabrics.
(2) Advanced Monitoring: Real-time moisture mapping using thermal imaging; AI-based drying prediction model.
(3) Automation: Auto-reset system after each test; motorized humidity control; self-cleaning condensate drainage.
(4) Batch Analysis: Compare multiple samples, export data in Excel or PDF.
(5) User-Friendly Operation: Touchscreen interface, programmable test cycles, and automated reporting.
Technical Parameters
| Parameter | Specification |
|---|---|
| Temperature Range | 20°C–60°C (±0.5°C accuracy) |
| Humidity Control | 30%–90% RH (programmable) |
| Drying Mechanism | Airflow circulation (0.5–2.5 m/s) + infrared heating |
| Moisture Detection | Capacitive moisture sensor (±0.1% accuracy) |
| Sample Size | Up to 500×500 mm (adjustable clamping frame) |
| Power Supply | 220V/50Hz, 1.8 kW |
| Dimensions | 1200×800×1500 mm (L×W×H) |
Accessories
Adjustable clamping frame for specimens
Water spray module for rain simulation
Data acquisition software for drying curves
Thermal imaging camera (optional)
Test Procedures
Sample Preparation: Cut specimens to 100×100 mm.
Calibration: Validate system with reference samples.
Testing: Start the cycle with predefined temperature and humidity.
Analysis: Generate drying curve and moisture loss graph.
Cleaning: Auto-drain condensate reservoir after testing.
