Fabric Touch Cool Feeling Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
Fabric Cooling Sensation Tester is used to evaluate the instant cooling sensation upon skin contact for textiles and sheet materials, such as nightwear, bedding, and undergarments.
Standards
GB/T 35263-2017 Textiles - Testing and Evaluation of Instant Cooling Sensation Performance
CNS 15687 Test Method for Instant Cooling Sensation Performance of Fabrics
FZ/T 50048-2020 Test Method for Instant Cooling Sensation Performance of Filament Chemical Fibers
FZ/T 73067-2020 Knitted Garments with Contact Cooling Sensation
FZ/T 62042-2020 Bedding Made from Cooling Fabrics
JIS L1927-2020 Textiles - Test Method for Determining Cooling Sensation Properties
FTTS-FA-019 Fabric Instant Cooling Sensation Verification Specification
T/CTCA 4-2018 Bamboo-Woven Cooling Mattress
Parameters
| Item | Specifications |
|---|---|
| Heated Plate & Bamboo Mat Probe Temperature | 20°C ~ 40°C |
| Temperature Resolution | 0.01°C |
| Temperature Sensor Response Time | 0.1s |
| Fabric Probe | Copper plate area: 9 cm², pressure: (0.1±0.01) N/cm² |
| Bamboo Mat Probe | Mass: 1.1 kg, heat flow meter dimensions: 100mm×50mm, measurement accuracy: 2% |
| Contact Coolness Coefficient (QMAX) Resolution | 0.001 J/cm²·s |
| Sample Size | Fabric: 200mm×200mm; Bamboo mat: 400mm×200mm |
| Test Environment Requirement | (20±0.5)°C (constant temperature and humidity chamber) |
| Power Supply | AC220V±10% 50Hz 100W |
| Instrument Dimensions (L×W×H) | 1000×580×446 mm |
| Weight | Approximately 40 kg |
Accessories
Fabric Probe: Copper plate with pressure control for consistent contact.
Bamboo Mat Probe: Simulates larger bedding or mattress samples.
Power Supply Cable: AC 220V compatible.
Calibration Kit: For temperature sensor verification and periodic validation.
Instruction Manual and Software Interface for test operation.
Test Procedures
1.Preparation:Ensure the instrument is on a stable desktop surface. Connect to power supply and allow it to reach ambient operating temperature.
2.Sample Placement:Place fabric or bamboo mat samples on the designated heated plate or probe area. Confirm proper alignment for uniform contact.
3.Parameter Configuration:Input desired test temperature (20–40°C) and measurement duration on the touchscreen interface.
4.Test Initiation:Start the automatic test. The system will heat the plate and record thermal response of the material, calculating the QMAX coefficient.
5.Data Recording:Test results are displayed on the screen in real-time and can be saved or exported for further analysis.
6.Completion:Remove the sample once the measurement is complete. Power off or proceed to the next test sample.
