6 station tester with RS232
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
1. Evaluating Material Fogging Performance
The fogging tester is primarily used to evaluate the evaporation of volatile components from interior materials of automobiles, aircraft, and other vehicles at high temperatures. These interior materials include plastic parts, polyurethane, textiles, leather, adhesives, non-woven fabrics, and thermoplastic elastomers. The test reveals the generation of volatile substances from the materials at high temperatures, thus determining their fogging performance.
2. VOC Detection
This instrument is one of the essential instruments for VOC (Volatile Organic Compounds) detection in the automotive interior industry. The test provides evaporation data of volatile substances from interior materials at high temperatures, providing important information for controlling indoor air pollution and ensuring the health of drivers and passengers.
3. Screening Environmentally Friendly Materials
Through testing with the fogging tester, environmentally friendly interior materials that meet environmental standards can be selected, helping automobile manufacturers improve the market competitiveness of their products while reducing environmental pollution.
Parameters
| Parameter | Specification |
|---|---|
| High-Temperature Range | Room temperature – 150°C (280°C optional) |
| Low-Temperature Range | 0–100°C |
| Temperature Stability | ±0.1°C (at 200°C) |
| Heat-Up Time | |
| Cooling Capacity | 500W (low bath) |
| Power Supply | AC 220V, 50Hz, 3.5kW |
| Dimensions | 500 (W) × 650 (D) × 600 (H) mm |
| Net Weight | 50 kg (excluding thermal media) |
| Data Interface | USB 2.0. remote sensor compatibility |
| Safety Systems | Magnetic switch, thermostat, audible alerts |
Accessoriess
Standard accessories：Main unit *1. constant temperature controller (cooling device) *1. glass beakers (fogging cups) *6.circular glass plates *6. square glass plates *6 (for reflection method testing), haze meter *1. metal rings *6.Fluororubber sealing rings *6. aluminum foil *1 pack, φ80mm sampler *1. dioctyl phthalate (DOP), silicone oil (heat transfer oil) / 32Kg, diisodecyl phthalate (DIDP)
Test Procedures
1.First of all , get the accessories and test samp.
2.Prepare an aluminum foil,place it in the scale to weigh it, and record the value.
3.Place aluminum foil and glass plate over the fog cup.
4.Set the cycle parameters of the low temperature control box, set host temperature and time parameters.
5.Start the instrument,the sample is heated inithe fog cup.
is started.When the timing is reached, remove.
the aluminum paper fZrom the station.
6.Put it into the scale again and weigh it, and record the value.
