Finger and hand abrasion tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
The applied load is set using dead weights, and the scrub (abrading) distance is adjustable from 1 to 4 mm, allowing precise adaptation to different test materials and geometries. This tester supports a wide range of applications, including mechanical abrasion and chemo-mechanical testing when liquids such as artificial sweat, hydraulic oil, or cleaning solutions are applied to the test fabric.
Technical Specifications
| Feature | Specification |
|---|---|
| Test Method | Simulates fingertip contact abrasion |
| Standard Compliance | IEC 68-2-70 |
| Test Load | Variable from 1 N to 100 N (set with dead weights) |
| Stroke (Scrub Distance) | Adjustable from 1 to 4 mm |
| Test Pistons | 10 mm and 20 mm diameter silicone test pistons |
| Cycle Counter | Pre-set digital counter |
| Operation Modes | Mechanical abrasion and chemo-mechanical abrasion |
| Dimensions (Approx.) | 100 × 80 × 60 cm |
| Power Supply | 110 V / 60 Hz |
| Construction | Precision-machined components for repeatable operation |
| Control Interface | Manual adjustment and digital cycle control |
Features
Realistic Human Contact Simulation: Accurately replicates fingertip abrasion under controlled load and stroke conditions.
Adjustable Parameters: Easily modify test load and stroke to suit different surface materials and textures.
Chemo-Mechanical Capability: Enables testing with liquids such as sweat or cleaning agents for enhanced realism.
Durable & Reliable Design: Built from precision aluminum and stainless steel components.
User-Friendly Controls: Simple setup with pre-set counter and intuitive adjustments.
Comprehensive Documentation: Supplied with operation manual, maintenance schedule, and replacement parts list.
Test Procedures
Measure and record specimen dimensions and thickness.
Secure the sample in the fixture and align properly.
Adjust fingertip mechanism height according to specimen thickness.
Install friction pad or chemical carrier.
Set load, friction stroke, and cycle count.
Start the device and monitor operation.
When the set cycle count is reached, the device automatically stops.
Remove the sample and evaluate surface appearance or performance changes.
Record and organize test results.
