Air Intake Filter Test System
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Air Intake Filter Test System is designed for testing industrial air filters and engine air filters according to ISO 5011. It evaluates filters’ performance for combustion engines and industrial machinery, providing precise measurements of pressure, dust loading, and particle filtration efficiency. The system supports both standard ISO testing and customer-specific protocols.
Application
This system is used for:
Engine Air Intake Filters: Testing filtration performance according to ISO 5011.
Industrial Air Filters: Performance testing for machinery intake filters.
Customer-Specific Standards: Flexible adaptation for custom test requirements.
Quality Control & R&D: Evaluating filter efficiency, dust holding capacity, and airflow restriction.
Standards
The system complies with:
(1) ISO 5011 – Air filter test for combustion engines and industrial machinery.
(2) ISO 12103-1 – Test dust (fine and coarse) for filter efficiency evaluation.
(3) ISO 10263 – Dust retention testing and gravimetric efficiency.
Parameters
| Parameter | Unit | Value |
|---|---|---|
| Test Flow Rate | m³/min | 2 … 50 (at 20°C and 1013 hPa) |
| Differential Pressure Measuring Range | Pa | ≤ 15,000 |
| Compressed Air Supply | bar | 6 |
| Power Supply | – | 400 VAC, 125 A |
| Test Aerosol | – | ISO 12103-1 A2 (fine), ISO 12103-1 A4 (coarse) |
