Garment Fabric Wet Adhesion Performance Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The garment fabric wet adhesion performance tester is used to evaluate the adhesion degree of clothing fabrics to human skin after being soaked in liquid.
Standards
1. T/CNGA 64-2024: "Test Method for Wet Adhesion of Garments"
2. FZ/T standard (Under review and pending release)
Technical Specifications
1. Evaluation system: Four-level wet adhesion performance grading system (Grade 1: Excellent, Grade 4: Poor)
2. Maximum load range: 300g
3. Force measurement range: 0.4%-100% FS
4. Measurement precision: 0.03% FS
5. Testing speed: 1-100mm/min
6. Maximum displacement: 80mm
7. Displacement precision: 10µm
8. Servo motor & driver: Panasonic
9. Dimensions: 545×419×509mm (W×D×H)
10. Power supply: AC 220V ±10%, 400W
11. Net weight: 25kg
Features:
1. Capable of testing the adhesion between garment fabrics and human skin from multiple angles.
2. Pre-loaded with established group and industry standards.
3. Features simple and user-friendly menu-driven software; the software is divided into multiple functional modules with a clean, intuitive interface that is easy to navigate at a glance. The software supports functions such as printing, data export, and real-time display of test curves.
4. Includes numerous extended functions to better support customer R&D activities.
5. Connects to a computer via dual serial ports, enabling comprehensive control of the testing process through dedicated PC software.
6. Equipped with a touchscreen display for enhanced visibility and ease of monitoring.
7. Utilizes advanced components to ensure rapid response times and high control precision, thereby guaranteeing the stability and accuracy of the test results.
