Geomembrane thickness tester
Get a quote:
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
This thickness gauge is meticulously designed and manufactured according to the thickness requirements specified in GB/T6672-2001 "Determination of Thickness of Plastic Films and Sheets - Mechanical Measurement Method" and SL 235-2012 "Standard Test Procedures for Geotechnical Synthetic Materials". The gauge has a simple structure, is easy to use, portable, and can be used for handheld measurements.
Application
Used to determine the thickness of smooth geomembrane and other plastic films under specified pressure and time. The sample is placed on the reference plate, and after a specified pressure is applied to the sample for a certain period of time with a circular press foot parallel to the reference plate, the vertical distance between the two plates is measured, and the geomembrane thickness is expressed as the average value of the test results.
Standard
GB/T 13761.1-2009:Geosynthetics - Determination of thickness at specified pressures - Part 1: Single layers
1S0 :Geosynthetics - Determination of thickness at specified pressures - Part 1: Single layers
GBT6672-2001:Plastics film and sheeting - Determination of thickness by mechanical scanning
1S04593-1993:Plastics; film and sheeting; determination of thickness by mechanical scanning
ASTM D5199-2001:Standard Test Method for Measuring the Nominal Thickness of Geosynthetics
JTG E50 T1112-2006:Thickness Determination of Geosynthetics
Features
Design and manufacture according to the standard, in line with the standard specifications;
With single and continuous measurement functions;
Press foot electric lifting, easy to operate;
Prescreening time can be set in advance to reduce manual error;
Using dial gauge measurement, high precision;
Measurement value digital display, easy to read.
Parameters
| Specification | Details |
|---|---|
| Measuring range | 0.001mm——20mm |
| Minimum division value | 0.001mm |
| Press foot diameter of medium | 10mm or 6.35mm |
| Working pressure | 2+0.01kPa, 20+0.1kPa, 200+1kPa |
| Power supply | AC 220V 50Hz |
| Overall dimensions | 440x210x395mm |
| Weight | 28kg |
