Rolling load tester EN 1569
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
A common requirement for different types of indoor sports surfaces is the measurement of rolling load. A rolling load tester is used to test the rolling action described in EN and DIN standards. The rolling load is determined by a loaded wheel rolling back and forth across the seams of the indoor sports surface. After the rolling is complete, the extent of damage and residual indentation can be determined as needed. This rolling load tester features an automatic lifting system and allows observation of the entire process through a transparent cover.
Applications
Different types of indoor sports surfaces
Standards
EN 1569: Determines rolling load resistance of synthetic sports surfaces (e.g., PU, PVC, rubber)
EN 14904: Tests performance of multi-sport indoor flooring under repetitive mechanical stress
DIN 18032-2: German standard for impact attenuation and deformation recovery in athletic facilities
Features
Rolling System:
Hardened Steel Wheel: 75mm diameter with 20° chamfer for seam simulation.
Pneumatic Load Application: ±1N accuracy via digital pressure regulator.
Control Panel:
7” TFT touchscreen with real-time cycle counter and load visualization.
USB/Ethernet ports for PC connectivity and remote diagnostics.
Safety Systems:
Emergency stop with E-Stop loop monitoring.
Overload protection at 110% of rated capacity.
Software Suite:
FloorDur Pro™: Auto-calculates deformation recovery (DIN 18032-2) and residual indentation.
Cloud Sport: Remote monitoring for global R&D teams.
Illumination:
Adjustable LED array (3.000–6.500K color temperature).
Auto-dimming function for operator comfort.
Technical Parameters
| Specification | Details |
|---|---|
| Load Range | 50N to 500N (adjustable in 1N increments) |
| Wheel Diameter | 75mm (EN 1569 compliant) |
| Cycle Speed | 1–10 cycles/minute (0.1 cycle resolution) |
| Sample Thickness | 2mm to 50mm (0.1mm resolution) |
| Power Supply | 220V/50Hz (110V/60Hz available) |
| Dimensions (W×D×H) | 600mm × 500mm × 1.200mm |
| Weight | 80 kg (net) |
