Electronic Single Fiber Strength Meter ASTM D3822
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Electronic Single Fiber Strength Meter is a precision instrument designed to measure the mechanical properties of single fibers, including breaking strength, elongation, and modulus. It integrates high-precision pneumatic clamps, microcomputer control, and real-time data acquisition to provide accurate, repeatable, and reliable fiber testing for research, quality control, and textile manufacturing applications.
Standards
The Electronic Single Fiber Strength Meter complies with:
GB/T 14337: Single fiber strength determination
GB/T 9997: Cotton fiber testing
GB/T 13835.5: Wool fiber testing
GB/T 21120: Silk fiber testing
ISO 5079: Textile – single fiber strength determination
ISO 11566: Wool fiber testing
ASTM D3822: Standard test method for tensile properties of single fibers
BS 4029: British single fiber testing standard
Features
(1) Microcomputer-controlled system with online communication capability.
(2) High-precision, high-speed force measurement system for accurate data.
(3) Patented pneumatic clamps providing constant clamping force to prevent fiber damage or slippage.
(4) Low-noise and stable drive system with precision ball screws and stepper motors.
(5) Direct USB connection for data transfer, report generation, graphics, and database management.
(6) Large-screen LCD with Chinese interface and printer output for test reports and curves.
(7) Memory function for storing up to 300 test data sets.
(8) LED-lit operating area for better visibility and sample handling.
Parameters
| Parameter | Specification |
|---|---|
| Mode | Constant Rate of Elongation (CRE) |
| Clamping Method | Pneumatic clamping |
| Force Measurement Range | 0~200 cN |
| Resolution | 0.01 cN |
| Measurement Accuracy | ±0.5% |
| Gauge Length | 5~60 mm (digital setting) |
| Maximum Elongation | 130 mm |
| Tensile Speed | 2~100 mm/min (digital setting) |
| Test Modes | Constant speed tensile, Load at specified elongation, Elongation at specified load, Creep, Initial modulus |
| Data Output Methods | LCD display (Chinese menu), Printer output of test reports and tensile curves |
| Printer Type | 24-pin dot-matrix |
| Power Supply | AC 220V ±10%, 50 W |
| Dimensions (H×W×D) | 450×510×580 mm |
