Taber Abrasion Resistance Tester ISO 9352
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Taber abrasion tester has a wide range of applications, covering multiple industries and fields. Its main application areas include:
1. Coatings Industry: Used to test the abrasion resistance of coatings to evaluate their durability and service life in practical use.
2. Plastics Industry: Used to test the abrasion resistance of plastic products to evaluate their service life under mechanical friction, chemical corrosion, and other environments.
3. Rubber Industry: Used to test the abrasion resistance of rubber products to evaluate their service life and performance under friction, extrusion, and other environments.
4. Paper Industry: Used to test the abrasion resistance of paper to evaluate its durability and quality during printing, writing, and other processes.
5. Textile Industry: Used to test the abrasion resistance of textiles to evaluate their durability and quality during wearing, washing, and other processes.
6. Flooring Industry: Used to test the abrasion resistance of flooring materials to evaluate their service life and performance under foot traffic, friction, and other environments.
In addition, the Taber abrasion tester is widely used in the automotive, electronics, and construction industries, providing strong support for material quality control and performance evaluation.
Standards
ISO Standards: ISO 9352. ISO 5470. ISO 7784
ASTM Standards: ASTM D1044. ASTM D3884. ASTM D4060
Chinese Standards: GB/T 5137.1. QB/T 2726
German Standard: DIN 53109
ASTM D3884. ASTM D1175. ASTM D1044. ASTM D4060. ASTM D4685.
TAPPI T476. ISO 9352. ISO 5470-1.
JIS K7204. JIS A1453. JIS K6902. JIS L1096. JIS K6964. DIN 52347. DIN 53109.
DIN 53754. DIN 53799. SATRA TM163
Features
Digital Control Interface: LCD screen displays real-time speed (30–75 RPM adjustable) and allows manual or programmed cycle settings.
Advanced Balance System: Rear arm equipped with interchangeable counterweights (250g, 500g, 750g, 1000g) for precise pressure control, including 125g ASTM compliance.
Adjustable Vacuum System: Height-adjustable suction port adapts to materials of varying thicknesses, efficiently removing debris during testing.
Modular Abrasion Wheels: Replaceable wheels (e.g., CS-10. H-18) and sandpaper discs (S-11) cater to diverse material testing needs.
Sample Preparation Kit: Includes sample stickers (S-36) and a diamond wheel polisher for pre-test surface conditioning.
Parameters
| Parameter | Specification |
|---|---|
| Rotational Speed | Adjustable: 30–75 RPM (digital control) |
| Sample Diameter | 100 mm |
| Test Platform Diameter | 113 mm |
| Cycle Range | 1–999.999 revolutions (presettable) |
| Air Pressure | 250g (standard) |
| Weight Options | 250g, 500g, 750g, 1000g (included); 125g (optional) |
| Wheel Pressure Range | 125g, 250g, 500g, 750g, 1000g, 1250g |
| Vacuum Arm Adjustment | Height-adjustable |
| Power Supply | 220V, 50Hz |
| Dimensions | 220 (W) × 380 (D) × 300 (H) mm |
| Net Weight |
20 kg |
