Automotive Wires Ozone Aging Chamber ISO 6722
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Automotive Wires Ozone Aging Chamber is designed to evaluate the ozone resistance of automotive wires and cables under controlled environmental conditions. You can simulate long-term exposure to ozone and temperature fluctuations, ensuring wire performance meets global automotive standards and OEM requirements.
Application
This chamber is suitable for testing:
(1) Automotive wires and cable bundles in engine compartments and electrical systems.
(2) Insulated wires for low-voltage automotive applications.
(3) R&D, quality control, and production line verification of wire ozone resistance.
(4) Rubber and plastic components in automotive parts requiring ozone aging assessment.
Standards
(1) ISO 6722 – Road vehicles: Electrical cables – Dimensions and test methods
(2) SAE J1128 – Low-voltage cables for automotive applications
(3) QC/T 730 – Automotive wire bundle ozone resistance test method (China)
(4) JASO D611 – Automotive parts: Ozone resistance test for rubber and plastics (Japan)
Parameters
| Parameter | Specification |
|---|---|
| Chamber Dimensions | 400 mm (W) × 500 mm (D) × 500 mm (H) |
| Temperature Range | RT +10°C to 60°C |
| Temperature Control | PID microprocessor, ±0.5°C stability |
| Temperature Uniformity | ±2°C across workspace |
| Ozone Concentration | 10–1000 pphm (adjustable), ±10% deviation |
| Rotation Speed | 0–5 RPM (adjustable via touchscreen) |
| Power Supply | 380V/50Hz (220V/60Hz optional) |
| Power Consumption | 3.5 KW (peak) |
| Noise Level | ≤65 dB |
| Controller | 7” touchscreen with multi-language support |
Features
(1) Dual-Zone Climate Control – Maintains precise temperature across the workspace with ±0.5°C stability.
(2) Advanced Ozone Generation – Corona discharge system with real-time concentration display and automatic calibration for consistent exposure.
(3) Rotating Sample Rack – 2 RPM adjustable rotation simulates mechanical stress during aging tests.
(4) Data-Driven Testing – Built-in data logger records temperature, humidity, and ozone levels; USB export enables traceable reports.
(5) Energy Efficiency – Rapid heating/cooling cycles with only 3.5 KW peak power consumption.
(6) Ergonomic Access – Full-view anti-ozone glass observation window and quick-release door seal for easy sample handling.
(7) Safety Certified – CE-marked with over-temperature protection and ozone leak detection for lab safety.
