Belt Abrasion Tester ASTM G132
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Belt Abrasion Tester is a laboratory testing instrument designed to evaluate the abrasive wear resistance of materials under controlled three-body abrasion conditions. You use a rotating pin pressed against a continuously moving abrasive belt under a constant dead-weight load, while both the pin rotation and belt speed are precisely controlled. An indexing linear slide ensures that the pin continuously contacts fresh abrasive material, providing repeatable and comparable wear results in accordance with ASTM G132.
Application
You can apply this tester in abrasive wear evaluation for the following materials and test scenarios:
(1) Abrasion resistance testing of metallic materials such as steels, non-ferrous alloys, powder metallurgy parts, and hard alloys.
(2) Wear performance evaluation of engineering ceramics and wear-resistant ceramic components.
(3) Abrasive wear testing of polymers, rubbers, engineering plastics, and composite materials.
(4) Performance comparison of surface-engineered materials including thermal spray coatings, PVD/CVD coatings, and protective wear coatings.
(5) Material screening and formulation comparison during product development.
(6) Quality control and consistency verification for industrial components.
(7) Research studies in tribology laboratories and academic institutions.
(8) Comparative testing between reference pins and test specimens under identical abrasive conditions.
Standards
ASTM G132 – Standard Test Method for Pin Abrasion Testing
Parameters
| Parameter | Specification |
|---|---|
| Pin Diameter | 2 – 10 mm |
| Pin Rotational Speed | 15 – 50 rpm |
| Maximum Load | 200 N (dead-weight loading) |
| Nominal Contact Pressure | 1 – 2.5 MPa |
| Sliding Speed | 10 – 100 m/s |
| Wear Path Length | 4 – 10 m |
| Belt Width | 100 mm |
| Belt Length | 1,200 – 2,000 mm |
| Standard Abrasive | 150-grit garnet |
| Optional Abrasives | 80 – 220 grit |
| Belt Drive | DC geared motor |
| Pin Drive | DC geared motor |
| Indexing Drive | AC servo motor |
| Test Temperature | Ambient |
| Control System | Touch-screen PLC |
