Automated Clutch Friction Test Machine
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Automated Clutch Friction Test Machine is a laboratory test system designed to evaluate friction, wear behavior, and thermal performance of wet clutch friction components under controlled load, speed, and lubrication conditions. The machine operates using a single original-manufactured friction pair, allowing detailed analysis of friction characteristics that cannot be obtained from full clutch pack or small-scale specimen testing.
The system supports precise speed control, closed-loop load application, temperature regulation, and automated data acquisition, making it suitable for standardized clutch friction research and comparative performance evaluation.
Application
The Automated Clutch Friction Test Machine is used for the following applications and components:
Wet clutch friction plate friction coefficient and torque characterization
Wear and durability evaluation of clutch friction materials
Engagement and disengagement behavior analysis under cyclic loading
Testing of small-scale friction components such as thrust washers
Friction performance assessment of limited-slip differential components
Evaluation of synchronizer and torque converter friction elements
Lubricant and friction material development and validation
Thermal behavior and heat dissipation studies of friction interfaces
Research, development, and quality control in automotive and transmission industries
Standards
GB/T 13986 — Determination of Friction Characteristics of Automotive Wet Clutches
JASO M349 — Test Method for Wet Clutch Performance
ISO 6312 — Automotive Clutch Friction Performance Testing
SAE J2491 — Clutch Friction and Wear Test Method
ASTM D3703 — Determination of Friction Properties of Friction Materials
Parameters
| Item | Technical Parameters |
|---|---|
| Friction pair size | Mean friction radius 35–125 mm |
| Maximum specimen diameter | 286 mm |
| Small specimen friction radius | 15 mm |
| Speed control ratio | 100:1 |
| Drive motor | AC motor, 4 kW, encoder feedback |
| Load range (low load) | 50 – 1,000 N |
| Load range (high load) | 250 – 10,000 N |
| Load actuation | Pneumatic bellows, closed-loop control |
| Torque measurement | Strain gauge torque transducer |
| Maximum torque | 180 Nm |
| Torque arm radius | 187 mm |
| Heating method | Electrical resistance heating |
| Heating power | 3 kW |
| Temperature range | 40 – 200 °C |
| Temperature sensor | Type K thermocouple |
| Cooling method | Circulating heat transfer fluid |
| Cooling flow rate | Up to 4 L/min |
| Controlled parameters | Speed, load, temperature, test duration |
| Measured parameters | Speed, load, friction torque, temperature, friction coefficient, time |
| Power supply | 380/415 V, three phase, 50/60 Hz |
| Compressed air | 4 cfm @ 8 bar |
| Cooling water | 10 L/min (typical) |
| Machine dimensions | 600 × 800 × 1,000 mm |
| Machine weight | 400 kg |
