Drawer slide durability testing machine
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Drawer Slide Durability Testing Machine is designed to evaluate the mechanical durability, operational reliability, and service life of drawer slide systems under repeated opening and closing cycles. The equipment simulates long-term daily use by applying controlled reciprocating push–pull motion to drawer slides, enabling accelerated life testing under standardized and repeatable conditions. It is used to identify wear, deformation, functional degradation, and potential failure modes of drawer slide assemblies in accordance with furniture hardware durability standards.
Application
(1) Durability and life cycle testing of furniture drawer slides (ball bearing slides, roller slides, concealed slides) used in residential and commercial furniture
(2) Performance evaluation of cabinet drawer slides (kitchen cabinets, bathroom cabinets, office storage units) under repeated opening and closing cycles
(3) Quality control testing for drawer slide manufacturers (steel slides, aluminum slides, soft-close slides) during production inspection
(4) Type testing and compliance verification of drawer slide systems for furniture hardware certification and standard conformity
(5) Research and development testing of new drawer slide designs, materials, and surface treatments to improve wear resistance and service life
Standards
(1) ANSI/BIFMA X5.5 – Desk Products: Tests for Drawer Durability and Performance
(2) BIFMA X5.5-2008 – Desk Products Durability and Functional Performance Requirements
(3) EN 15338 – Furniture Hardware – Strength and Durability Requirements for Drawer Slides
(4) ISO 7170 – Furniture – Storage Units – Determination of Strength and Durability
(5) QB/T 2454-2013 – Furniture Hardware – Drawer Slide Rails
Features
(1) PLC control system combined with stepper motor drive ensures high repeatability and precise control of test motion
(2) Adjustable reciprocating push–pull speed allows simulation of different usage frequencies and operating conditions
(3) Programmable test counter with automatic shutdown enables unattended long-duration testing
(4) Wide adjustable mounting width with linear bearing structure supports a broad range of drawer slide sizes and types
(5) Multi-station design improves testing efficiency and allows parallel evaluation of multiple samples
Parameters
| Item | Description |
|---|---|
| Reciprocating speed | 1–15 times/min, adjustable |
| Test cycle counter | 1–999.999 cycles, preset with automatic stop |
| Push–pull stroke | 100–600 mm, adjustable |
| Control mode | PLC control, adjustable slide stop time |
| Installation width | 100–900 mm, adjustable |
| Slide mounting structure | Ø30 mm guide rod with linear bearing |
| Test stations | 1–6 stations |
| Drive motor | Stepper motor, PLC program controlled |
| Power supply | AC 220 V, 60 Hz |
