Toyota Specialized Abrasion Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Toyota Special Abrasion Tester is a precision wear testing instrument designed to evaluate the abrasion resistance, frictional colorfastness, and color transfer of materials such as leather, fabrics, plastics, and polymers. The tester features four independent test stations, each equipped with a 1 kg friction head, allowing simultaneous testing of up to four specimens. Each sample fixture can apply up to 10% tensile force when secured to the oscillating test bed, ensuring accurate simulation of real-world stresses.
Application
(1) Testing leather, fabric, and synthetic materials for abrasion resistance
(2) Evaluating colorfastness and color transfer under repeated friction
(3) Assessing material durability for automotive interiors, upholstery, footwear, and technical textiles
(4) Simultaneous multi-sample testing to improve laboratory efficiency
(5) Applicable in R&D laboratories, quality control departments, and material certification labs
Standards
(1) TSL 5100G Section 4.24 – Toyota abrasion testing standard
(2) TSL 5101G Section 3.9.1 A – Toyota colorfastness and friction specification
(3) GB/T 3920 – Colorfastness to rubbing (textiles)
(4) AATCC 8 – Colorfastness to crocking (textiles)
(5) AATCC 165 – Colorfastness to rubbing (leather)
(6) ISO 105-X12 – Textiles – Colorfastness to rubbing
(7) ISO 105-D02 – Textiles – Colorfastness to rubbing
(8) JIS L0849 – Textile colorfastness to rubbing
(9) M&S C8 – Martin & Server textile rubbing specification
Parameters
| Feature | Specification |
|---|---|
| Product Weight | 54 kg (120 lbs) |
| Dimensions | 432 × 660 × 559 mm (17" × 26" × 22") |
| Number of Test Stations | 4 independent stations |
| Friction Head Weight | 1 kg each |
| Sample Tensile Force | Up to 10% of elongation applied during testing |
| Friction Head Types | Square: 19 × 25.4 mm rectangle; Cylinder: Ø16 ± 0.1 mm |
| Construction | Aluminum and stainless steel mechanical components |
| Drive System | High-quality brushless electric motor |
| Bearings | THK precision bearings |
| Controller | Programmable count-up with automatic stop |
| Protective Features | Ventilated cover to protect operator hands |
| Surface Finish | Durable powder coating and anodized surfaces |
| Electrical Supply | Specified at purchase; multiple voltage options available |
