IULTCS/Veslic Rub Fastness Tester | ASTM ISO Testing Machine

•

Get a quote：

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

Standards

IS0 11640 Leather-Tests for colour fastness-colour fastness to cycles of to and fro rubbing

SATRA PM 173 Colour fastness to rubbing-reciprocating method

QB/T 2537 Leather-Tests for colour fastness-colour fastness to cycles of to and fro rubbing

GB/T 20991 7.3 Determination of abrasion resistance of insole

EN IS020344 7.3 Determination of abrasion resistance of insole

AS/NZS 2210.2 7.3 Determination of abrasion resistance of insole

ISO 17700 Method A To and fro square rubbing finger fastness testing Footwear-test methods for upper components and insocks-colour fastness to rubbing

DIN 4843 Safety footwear safety requirements testing

QB/T 2226 Shoelace wear test method, light industry standards.

Consumables

Friction material:

White wool felt, size 15mm × 15mm. The punched pure wool felt piece should meet the following requirements: pH of water extract between 5.5 ~ 7.0; mass per unit area (1750 ± 100) g / m2. thickness (5.5 ± 0.5) mm.

Technical Parameters

1. Test bench: a horizontal metal platform; a holder for fastening the leather to the platform, leaving approximately 80mm exposed; a device with which the leather may be extended 10% to 20% linearly in the direction of rubbing (sample size 120mm × 20mm).

2. Test column: weight (500 ± 25) g. It can be moved, but also firmly fixed. including:

A) Test head area: 15mm × 15mm.

B) Device for adjusting the test head to bring the felt pad into horizontal contact with the test platform.

C) Load bearing blocks: (500 ± 10) g. After loading, the total mass of the test column is 1000g.

D) Adjustment device: adjust the test column up and down so that the test head makes horizontal contact with sample.

3. Device that drives test bench for reciprocating motion: test head makes forward-backward motion with a stroke of 35mm ~ 40mm at a frequency of (40 ± 2) cycles / min.

4. Counter: LCD digital display, round-trip as one time, the number of cycles can be set to 5 to 500 times.

5. Device that can adjust the test column in the horizontal direction (optional): the test head can be rubbed against the leather samples at 2 to 3 different angles.
