Surface Water Absorption Tester
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Fabric Water Absorption Tester is designed to test the ability of terry fabric to rapidly absorb and retain liquid water from surfaces such as human skin, dishes, and furniture in accordance with ASTM D 4772.A measured amount of water is poured into the funnel and onto the fabric that has been secured to the fixture. The water captured in the lower pan is subtracted from the original amount to determine the amount of water that was absorbed.
Application
(1) Woven, knitted, and nonwoven fabrics
(2) Sportswear and functional textiles
(3) Medical fabrics and hygiene products
(4) Home textiles such as towels, bedding, and curtains
(5) Research and quality control laboratories
Standards
GB/T 22799. ASTM D 4772
Scope of application:
Fabric, Leather & Vinyl Testers
Feature
1. The mounting seat is made of 304# stainless steel, rustproof and durable.
2. The specimen holder can be adjusted left and right to meet the standard requirements.
3. Sample installation is simple and convenient.
Parameter
Model：Q121
Flow tube：50ml
Funnel：150ml
Specimen placement angle：60° to the horizontal
Distance between the outlet end of the water pipe and the surface of the specimen：2mm~ 10mm; from the inside of the outer ring of the card ring: 28mm~32mm
Specimen holder diameter： Standard φ150mm (GB/T standard) optional φ153mm (ASTM standard)
External dimensions：380*180*480mm
Weight：7.4kg
