ASTM F970 Carpet Dynamic Load Tester
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Carpet Dynamic Load Tester is also known as a dynamic load machine. It provides information on the reduction in the thickness of carpet pile by imitating the shearing effects of two actions: the pressure during walking and that from the edges of shoes.
Application
You can use this machine to test:
Residential, commercial, and industrial carpets
Rugs and area mats
Textile flooring products
Quality control and R&D of pile height retention and wear resistance
Standards
The instrument supports international carpet durability testing standards, including:
(1) ISO 2094:1999 (Carpets – Determination of dynamic load resistance)
(2) BS 3654 / ISO alignment (British standard for carpet durability)
(3) QB/T 1091-2001 (Chinese textile flooring standard)
(4) ASTM D3574 Test I4 (US standard for foam and carpet performance)
Parameters
| Parameter | Specification |
|---|---|
| Dimensions (W×D×H) | 500 mm × 500 mm × 370 mm |
| Power Consumption | 250 W |
| Load Type | Two rectangular steel feet (51 mm × 6.3 mm, height 9.5 mm) |
| Impact Frequency | One impact every 5 seconds |
| Sample Movement | 3.2 mm per impact with semi-overlapping area |
| Stressed Area per Cycle | 90 mm × 50 mm |
| Test Mode | Dynamic back-and-forth motion |
Features
Accurately simulates walking pressures and shearing effects on carpet pile.
Provides quantitative measurement of carpet pile reduction for durability evaluation.
Compliant with British, Chinese, and international standard testing methods.
Compact design for easy installation in laboratories and R&D facilities.
Accessories
(1) 1 × Operation Manual
(2) 1 × Calibration Certificate (if applicable)
(3) 1 × Set of steel impact feet
