Acid and Alkali Protective Clothing Splash and Spray Liquid Tightness Tester
Getaquote:
Whats/App: +86 181 0160 0864
The Acid and Alkali Protective Clothing Splash and Spray Liquid Tightness Tester is designed to evaluate the liquid-tightness performance of acid and alkali chemical protective clothing under splash and spray conditions. It simulates realistic chemical spray exposure to help you verify whether protective garments can effectively prevent liquid penetration during use.
Application
You use this tester to assess splash and spray liquid tightness of acid and alkali chemical protective suits.
It is suitable for testing full-body chemical protective clothing, acid-resistant suits, alkali-resistant suits, and related chemical protection garments used in industrial production, laboratory environments, and chemical handling operations.
Standards
The Acid and Alkali Protective Clothing Splash and Spray Liquid Tightness Tester complies with the following standards:
ISO Protective clothing. Test methods for protective clothing against chemicals. Part 3: Determination of resistance to liquid jet penetration (jet test)
ISO Protective clothing. Test methods for protective clothing against chemicals. Part 4: Determination of resistance to liquid spray penetration (spray test)
GB 24540-2009 Appendix I Protective clothing Acid-base chemical protective clothing Splash tightness test method
GB 24540-2009 Appendix J Protective clothing Acid-base chemical protective clothing Spray liquid tightness test method
GB24539-2009 Appendix B Test Method for Liquid Penetration Performance of Chemical Protective Clothing
GB24539-2009 Appendix C Test Method for Liquid Tightness Performance of Chemical Protective Clothing
Parameters
| Item | Specification |
|---|---|
| Turntable Speed | 1 rad/s |
| Nozzle Installation Spacing on Spray Arm | 450 mm |
| Nozzle Spray Angle | 75° |
| Nozzle Spray Pressure | 300 kPa |
| Nozzle Flow Rate | (1.14 ± 0.1) L/min |
| Time Setting Range | 0–99.99 s |
| Time Resolution | 0.01 s |
Features
You test garments using a specially designed mannequin that simulates realistic human movement.
A waterproof turntable rotates at a constant speed to ensure uniform spray exposure.
The water supply system includes a pressure gauge and flow adjustment device for stable spray conditions.
Spray duration can be preset with automatic timing control.
A fully enclosed protection system surrounds the equipment to ensure laboratory safety.
A self-priming circulation hydraulic pump provides fast liquid supply with stable pressure.
The mannequin can perform leg lifting, arm swinging, and static postures during testing.
The control system and test chamber are separated to prevent contamination of electrical components.
A color touchscreen with menu-based operation ensures easy and intuitive control.
A 32-bit microcontroller-based multifunction control board ensures stable system performance.
Precision motor control allows accurate speed regulation and positioning.
Accessories
(1) Main testing unit
(2) Mannequin assembly
(3) Spray arm and nozzle assembly
(4) Circulation pump system
(5) Power cable
(6) User manual
(7) Certificate of conformity
Test Procedures
You dress the mannequin with the protective clothing to be tested.
Set spray parameters and test time via the touchscreen interface.
Start the test, and the turntable rotates while the spray system applies liquid to the garment.
The mannequin performs preset movements during spraying.
After the test, you inspect the inner surface of the garment to evaluate liquid penetration.
Maintenance Information
You should clean the spray system and circulation pipelines after each test.
Nozzles and flow meters should be checked regularly to ensure accurate spray conditions.
Mechanical moving parts should be inspected to maintain smooth operation.
Electrical components and seals should be checked periodically to ensure long-term reliability.
