Glass Scratch/Abrasion Tester | ASTM ISO Testing Machine
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Glass Scratch/Abrasion Tester is used to test the scratch and abrasion resistance of glass. This instrument uses a counter to set the number of rubbing cycles and a speed controller to adjust the operating speed of the rubbing head to meet the customer's actual testing needs. During the test, a 10mm*10mm rubbing head equipped with steel wool is used. Adjustable weights adjust the pressure load of the rubbing head to rub the glass. After the test, the sample is removed and its scratch and abrasion resistance is evaluated.
Applications
Automotive Glass: Assesses windshield durability against environmental wear.
Consumer Electronics: Tests smart screens, tablet covers, and display panels.
Architectural Glass: Validates window and facade materials for long-term performance.
Medical Devices: Ensures compliance with biocompatibility standards (e.g., ISO 10993-7).
Standards
ISO 10993-7: Biological Evaluation of Medical Devices – Ethylene Oxide Sterilization Residuals
USP (United States Pharmacopeia): Container Performance Testing
Ph. Eur. (European Pharmacopoeia): Glass Containers for Pharmaceutical Use
JP (Japanese Pharmacopoeia): Glass Container Testing Standards
GB/T 16886.7: Biological Evaluation of Medical Devices – Ethylene Oxide Sterilization Validation
Features
Three Independent Workstations: Enables parallel testing of diverse glass types.
Adjustable Friction Head: 10mm × 10mm steel wool attachment with load regulation (0–10N).
Speed Governor: Controls reciprocating motion (50 ±5 mm stroke) up to 120 RPM.
Safety Interlocks: Prevents accidental start-up and overload damage.
Easy Sample Handling: Quick-release clamps for rapid sample exchange.
Digital Display: Monitors test parameters (load, speed, cycles) in real time.
Technical Parameters
| Parameter | Specification |
|---|---|
| Control Mode | Automatic (PLC) |
| Maximum Load | 10 N (Adjustable) |
| Speed Range | 0–120 RPM (Reciprocating) |
| Stroke Length | 50 ±5 mm |
| Workstations | 3 (Independent) |
| Friction Head Size | 10 mm × 10 mm (Steel Wool Attachment) |
| Power Supply | AC 220V ±10%, 50Hz |
| Dimensions (L×W×H) | 800 mm × 400 mm × 500 mm |
| Net Weight | 85 kg |
| Display | LED Touchscreen (Load/Speed/Cycle Control) |
