Wire Reciprocating Swing Bending Tester
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Wire Swing Bending Tester is designed to simulate bending and swinging conditions that wires may encounter during actual use, such as automotive wires, power cords, and USB cables. By adjusting parameters like bending angle, swing frequency, and test duration, the tester evaluates the durability and reliability of wires under repeated mechanical stress.
Standards
(1) UL 817 – Standard for cord sets and power-supply cords
(2) VDE 0620 – Standard for flexible cables for household appliances
(3) GB 2099 – Chinese standard for household and similar electrical wires
Parameters
| Parameter | Specification |
|---|---|
| Test Speed | 10–60 cycles/min (adjustable) |
| Bending Angle | 10°–180° adjustable (commonly 30°, 45°, 60°, 90°, 120°, 150°, 180°) |
| Test Stations | 6 simultaneous wire samples per test |
| Bending Cycles | 0–999.999 cycles adjustable |
| Applied Weights | 50 g, 100 g, 200 g, 300 g, 500 g (6 pieces) |
| Automatic Counter | 6 LCD counters, one per test station |
| Dimensions | 850 × 600 × 750 mm (L×W×H) |
| Weight | Approx. 100 kg |
| Power | 95 W |
| Power Supply | AC 220 V / 50 Hz |
Application
(1) Automotive wiring harness testing – assess bending fatigue and durability of automotive wires.
(2) Power cord quality evaluation – ensure long-term mechanical reliability.
(3) USB and data cable testing – simulate repeated use conditions.
(4) Electrical appliance wiring – evaluate insulation and mechanical integrity.
(5) R&D laboratories – test new insulation materials for bending and fatigue resistance.
Features
(1) Simulates real-world bending and swinging stress on wires.
(2) Adjustable bending angles and test speed to cover a wide range of wire applications.
(3) Multiple test stations enable simultaneous testing of up to six wire samples.
(4) Accurate cycle counting via integrated LCD counters.
(5) Supports a variety of weights to simulate different mechanical loads.
(6) Sturdy construction ensures consistent, repeatable test results.
