ISO 11057 Filter media performance testing System

Get a quote:

Whats/App: +86 156 1874 6768

Web: standard-groups.com

The Aerosol Sensor Test System is designed for development, testing, and calibration of active and passive aerosol sensors, including PM and PN sensors. It combines features from filter media test systems with flexible sensor integration and broad flow ranges, enabling accurate evaluation of particle mass or number concentration. The system can be configured with two measurement sections to cover flow rates from 0.8 m³/h to 450 m³/h.

Features

Stable and Adjustable Aerosol Generation: Provides consistent aerosol concentrations across variable flow rates.

Solid and Liquid Aerosol Capability: Supports both types of aerosols to meet diverse test requirements.

Customer Customization: Adapts to different sensors, sample holders, and measurement configurations.

Broad Application Range: Suitable for PM and PN sensor calibration, testing, and development.

Fully Integrated System: Seamless integration with external equipment for optimal performance.

User-Friendly Software Control: Win-based interface for simplified operation, data acquisition, and result analysis.

Accessories

AccessoryQuantity
Aerosol Generator 1
Laser Aerosol Particle Spectrometer 1
Sample Holder As required
Customer-Specified Sensors/Equipment As required

Standards

This system complies with and supports:

(1) GB/T 14295-2019 – Air filters.

(2) GB/T 13554-2020 – High-efficiency air filters.

(3) GB/T 6165-2021 – HEPA filter performance: efficiency and resistance.

(4) ISO 11057 – Filter media performance testing.

(5) EN 1822-4 – HEPA filter testing.

(6) ISO 29463-4 – High-efficiency air filter performance.

(7) ASTM D6830 – Evaluation standard for air filters.

Parameters

ParameterUnitValue
Test Flow Rate m³/h 0.8 – 450
Test Concentration µg/m³ 5 – 1000 (at 100 m³/h)
Test Medium Differential Pressure Pa ≤ 10000 (for 450 m³/h)
Gas/Air Supply Compressed air, max. 10 bar
Power Supply 400 VAC, 25 A
Particle Measurement Customer-specified (e.g., LAP 323)
Sensors Differential pressure, temperature, relative humidity, absolute pressure
Duct Diameter mm 150 (internal)
System Dimensions (W × H × D) mm 2300 × 1500 × 900
Weight kg approx. 400
