Thermal Insulation Rock Wool Thermal Load Test Device
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The thermal insulation rock wool thermal load test device is a test device developed according to the technical conditions stipulated in the National Standard GB/T11835-2007 "Adiabatic Rockwool, Slag Cotton and Products" of the People's Republic of China.
Application
Industrial Insulation: Verifying the high-temperature resistance of rock wool insulation layers in equipment such as pipes, storage tanks, and boilers to ensure structural stability, reduce heat loss, and meet safety standards.
Building Energy Efficiency: Evaluating the thermal stability and fire resistance of rock wool insulation materials for exterior walls and roofs, preventing deformation or cracking at high temperatures, and improving building energy efficiency and safety.
Marine Fire Protection: Testing the shrinkage resistance and thermal insulation capabilities of marine rock wool insulation materials under high-temperature fire conditions to ensure the safety of ship structures.
Energy Engineering: Selecting rock wool materials for high-temperature equipment in nuclear power and thermal power plants, verifying their long-term temperature resistance to ensure the safe operation of energy systems.
Scientific Research and Quality Inspection: Supporting the development of new materials and the establishment of standards, providing accurate thermal load data, and promoting technological upgrades in the rock wool industry.
Standards
GB/T11835-2007: Thermal insulation rock wool, slag wool and its products
ISO1716-2002 :Reaction of building products to flame test Determination of heat of combustion
Features
The product has reasonable structure, high touch screen control, high degree of automation, accurate recording time, stable performance and convenient operation.
Parameters
| Item | Description |
|---|---|
| Control Interface | Seven-inch full-color touch screen, multi-point program heating |
| Ambient Conditions | Temperature: Room temperature to 40℃; Relative humidity: ≤75% |
| Working Voltage | AC 220V±10V, 50HZ |
| Power Specifications | Total power: 2.5KW; Heating power: 1000W |
| Temperature Measurement Range | Room temperature to 900°C |
| Heating Rate | From room temperature to 400℃: 5°C/min; From 400℃ to 800℃: 3°C/min |
| Control System | Single-chip computer with multi-point program heating |
| Fixture Material | Stainless steel, anti-corrosion |
| Heat Source | Hot plate |
| Sample Pressure | 490pa |
| Test Barrel Dimensions | 48mm±1mm in diameter |
| Equipment Weight | 50 Kg |
