Vertical Fire Resistance Test Furnace for Building Elements
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Vertical Fire Resistance Test Furnace for Building Elements is designed for fire resistance testing of vertical building components, including non-loadbearing vertical partitions, fire doors, and fire shutters. The furnace is manufactured in accordance with the technical requirements of GB/T 9978. integrating the furnace body, furnace roof, steel test platform, exhaust and air supply system, combustion and gas supply system, and a comprehensive test control system.
With built-in calibration capability, the system ensures that furnace temperature, pressure values, and distribution meet standard requirements, making it suitable for standardized fire resistance testing and performance evaluation of vertical building elements.
Application
Vertical Building Elements
Fire resistance testing of non-loadbearing vertical partitions, walls, and separation elements.
Fire Doors and Fire Shutters
Performance evaluation of doors, rolling shutters, and related assemblies under standard fire exposure.
Building Fire Safety Evaluation
Verification of fire resistance performance for construction materials and assemblies used in buildings.
Fire Testing Laboratories and Certification Bodies
Standardized testing for product certification, compliance verification, and research applications.
Standards
The equipment complies with the following standards:
(1) GB/T 9978.4-2008 – Fire Resistance Tests — Elements of Building Construction — Part 4: Specific Requirements for Loadbearing Vertical Separating Elements
(2) GB/T 9978.8-2008 – Fire Resistance Tests — Elements of Building Construction — Part 8: Specific Requirements for Non-loadbearing Vertical Separating Elements
(3) GB/T 7633-2008 – Fire Resistance Test Methods for Doors and Shutters
(4) ISO 834 – Fire Resistance Tests — Elements of Building Construction
(5) EN 1363 – Fire Resistance Tests for Building Elements
Parameters
| Item | Specification |
|---|---|
| Number of Burners | 12 proportional flat-flame burners (6 on each side, 5 m furnace length) |
| Operating Temperature | Maximum test temperature 1250 °C |
| Design Temperature | 1350 °C |
| Combustion Mode | Low-speed proportional flat-flame diffusion combustion |
| Gas & Air Pressure | ≤ 4000 Pa |
| Flame Length | ≤ 500 mm |
| Furnace Temperature Measurement Points | 9 points |
| Thermocouple Sleeve Extension | ≥ 25 mm |
| Temperature Accuracy | < ±15 °C |
| Fuel Gas | Liquefied petroleum gas |
| Equipment Dimensions | 3 m (W) × 3 m (L) × 1.25 m (H) |
| Power Supply | AC 380 V, 70 kW |
| Equipment Weight | Approx. 5 t |
