Automatic Thermal Deformation Vicat Softening Point Tester
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
This machine is a non-metallic material testing instrument designed and manufactured according to the latest international standards and national standards. It is mainly used for non-metal such as plastic, hard rubber, nylon, electrical insulating materials, long fiber reinforced composite materials, high strength thermosetting laminates. Determination of the heat distortion temperature of the material and the Vicat softening point temperature. It is easy to operate and precise in control. It is a highly intelligent test instrument widely used in colleges and universities, research institutes and product quality supervision and inspection units. It adopts single-chip control, PID phase-modulated output, with upper limit temperature setting, and automatically stops heating when the test temperature reaches the upper limit temperature..
Applications
plastic, hard rubber, nylon, electrical insulating materials, long fiber reinforced composite materials, high strength thermosetting laminates.
Standard
(1)GB/T1633《Determination of vika softening temperature (VST) of thermoplastic》
(2)GB/T1634《Determination of plastic load deformation temperature – part 1: general test method》
(3)GB/T8802《Determination of softening temperature of plastic pipe fittings》
(4)IS075-2013《Measurement of plastic load deformation temperature》
(5)ASTM D 648《Test method for temperature of plastic thermal deformation》
(6)ASTM D 1525《Plastic Vicat softening test method》
parameters
| Temperature control range | ambient temperature~300ºC |
| Heating rate | (120±10)ºC/h (12±1)ºC/6min,(50±5)ºC/h (5±0.5)ºC/6min |
| Temperature indication error | 0.1ºC |
| Temperature control accuracy | ±0.5ºC |
| Maximum deformation indication error | ±0.001mm |
| Deformation measurement range | 0-10mm |
| Number of sample racks | 3 |
| The weight of the load bar and the tray | 76g |
| Test span range | 64 or 100mm according to the standard |
| Fuel tank volume | about 13L |
| Heating medium | methyl silicone oil |
| Cooling method | built-in active air cooling or external water cooling |
| Heating power | 2kw |
| Appearance size | length 65cm*width 46cm*height 84cm |
