Features
Dual-Roller System: Separate rollers for hook (male) and loop (female) surfaces ensure consistent contact pressure during cycling.
Adjustable Test Cycles: Programmable up to 999.999 repetitions to meet diverse standard requirements.
Heavy-Duty Wheel: Applies calibrated pressure to simulate high-stress use cases (e.g., footwear, automotive interiors).
Ergonomic Controls: Intuitive interface with LCD display for real-time cycle tracking and error diagnostics.
Safety First: Overload protection and emergency stop function guarantee operator safety.
Modular Design: Fixtures and rollers are interchangeable for compatibility with various fastening tape geometries.
Parameters
| Item | Specification |
|---|---|
| Roller diameter | Upper roller: φ162.5mm, Lower roller: φ160mm |
| Roller width | Generally 70mm or 80mm |
| Rolling speed | 60rpm/min (or 60±5r/min) |
| Reversing time | 30s |
| Load | 5kg |
| Counter | LCD display, 0~999.999 cycles |
| Horsepower | AC 1/8HP dual-frequency motor |
| Power supply | AC220V, 50Hz |
| Dimensions & Weight | Vary by model |
Test Procedures
First: Prepare the weights and test sample;
Attach the Velcro tape to the roller surface;
Attach the two rollers together;
Add the weights;
Set the timer;
As the rollers roll, the Velcro tape will continuously adhere and peel off;
When the timer ends, the rollers will stop working.
