Cleanable Filter Media Testing Rig

Whats/App: +86 156 1874 6768

Web: standard-groups.com

Applications

Quality assurance of flat sheet filter media in terms of a final clearance and a receiving inspection

performance testing of filter materials during research and development stage.

Standards

GB/T 6165 — High Efficiency Air Filters — Performance Test Methods

GB 2626 — Respiratory Protection — Non-powered Air-Purifying Particle Respirators

EN 13274-7 — Respiratory Protective Devices — Test Methods — Part 7: Determination of Particle Filter Penetration

ISO 5011 — Inlet Air Cleaning Equipment for Internal Combustion Engines and Compressors — Performance Testing

ISO 29463-3 — High-Efficiency Filters and Filter Media for Removing Particulate Matter in Air — Part 3: Testing Flat Sheet Filter Media

ISO 29463-5 — High-Efficiency Filters and Filter Media for Removing Particulate Matter in Air — Part 5: Test Method for Filter Elements

Technical data

ParameterUnitValue
Test flow rate m³/h 1.5-18
Measuring range, differential pressure Pa 5000
Compressed air supply (operating gas/air) bar 6
Power supply 110 … 230 VAC, 50/60 Hz
Operating medium (aerosol) DEHS, ISO 12103-1 A2

Principle

- Flow rate unit: injector pump with a set of critical nozzles to adjust different flow rates

- Intake test air is directed through a special intake section for homogenous mixing with the test aerosol

- Test filter holding manually operable

- Solid aerosol generator exchangeable by different models of the series

- Control of the Solid Aerosol Generator integrated to the test rig

- Test dust dispersion by using an injector nozzle

- Suitable especially for test dusts ISO 12103-2 A2/A4

Accessories

Differential pressure measurement

Fractional efficiency measurement:

- Aerosol Spectrometer

- Aerosol Dilution System

- Sample Switching, controllable by means of software of aerosol spectrometer or via serial interface
