Industrial Oil Separator Test Machine

Whats/App: +86 156 1874 6768

Web: standard-groups.com

Standards

ISO 11155 series – air filtration and separator standards

DIN 71460-1/2 – cabin and related oil mist separator standards

ISO 12103-2 – test dust and particle characteristics

ISO 5011 – filter media performance testing (referenced for separator elements

ISO/TS 16332-2006 – Road vehicles — Crankcase ventilation systems — Test method for oil mist separators

ISO 4020-2001 – Rubber — Determination of effect of liquids on material properties (applicable if testing rubber components of separators)

SAE J905-1999 – Automotive CCV systems — Test methods for crankcase ventilation oil separators

Features

compact test bench

wide range of flow rate

sample holder adjustable for different sample dimension

heated oil mist generator (maximum 120°C)

closed loop system for different pressure regimes

possibility of opening up the secured testing channel

heatable Aerosol Generator ATM 243 also utilizable without SPT 140

Software guided testing procedure

test rig control and data acquisition software for Windows

precise flow rate analysis

Technical data

Parameter titleUnitValue
test flow rate m³/h 0.9 ... 18 or 1.2 ... 24
testaerosol - dropletaerosolbased on mineral or synthetic engine oil
differential pressure of test specimen Pa ± 20000
operating medium, gas/air - room air (common laboratory conditions)
operating medium, gas/air - compressed air supply bar max. 6 (300 L/min)
operating medium, water - water supply bar max. 6 (from water network, max. 20 L/h, for cooling circuit)
power supply - 400 V, 16 A
aerosolgeneration technology - ATM 243 or LDG 243 (optional)
dimensions (w × h × d) mm 2100 × 1200 × 925
weight kg approx. 400

Accessories

oil droplet generator LDG 244 to produce large droplets for the simulation of oil film and oil gush effects

Test Procedure

Install the separator in the adjustable sample holder, ensuring complete sealing.

Start the oil mist generator and set the flow rate and temperature.

Start the automated test program; software guides the test process.

Measure separation efficiency, oil leakage, and differential pressure changes.

Record pressure regulation curves and flow characteristics.

Upon completion, move the separator to a safe area; software generates the test report.

Export data for long-term analysis, performance optimization, and standard compliance.
