N Condensate Pump
Product name:N Condensate Pump
Model:N Condensate Pump
Application:condense water vapor and 750-3000 kW Condensate pumping turbine generator set and other similar applications use.
Product overview
N-type condensate pump Overview:
Condensate pump is to transport condensate products. N-type pump for conveying a temperature below 120 ℃ condensate or physical and chemical properties similar to water liquid, NB, NBA, NBA-type pump for pumping temperature does not exceed 80 ℃ condenser to condense water vapor and 750-3000 kW Condensate pumping turbine generator set and other similar applications use.
N-type condensate pump parameters:
Traffic Q: 10-100m3 / h
Head H: 12-141m
N-type condensate pump Model significance:
3N6x2
3-- pump inlet diameter of 3 inches
N-- horizontal cantilever condensate pump
6-- designed head in addition to 10 after rounding
2-- pump series is 2
100NB-45
Import pump is 100mm caliber 100--
N-- condensate pump
B-- suspension type
45-- pump design head of 45m
N-type condensate pump Structure Description:
N, NB, NBA-type pump is single stage single suction cantilever centrifugal pump, N-type two-level structure, the rest of the horizontal structure. Pumps with wheels and pulleys induced without inducing two structural formula. Compact, smooth and reliable operation, high efficiency, good anti-cavitation performance. Standardized design, high degree of standardization common good.
Material flow components: steel or stainless steel, different materials can also be selected according to user requirements.
| type | flow Q |
Range H |
Rotational speed n |
Shaft power Pa |
Electric motor | Efficiency n |
Steam eclipse amount | Impeller diameter | Imported caliber | Outlet diameter | Weight |
||
| m3/h | L/s | m | r/min | kw | Powerkw | type | % | m | mm | mm | mm | kg | |
| 100N130 | 70 52.5 42 |
19.45 14.6 11.7 |
135 141 143 |
2950 | 46. 40 368 |
55 | Y250M-2 | 55 49 44 |
2.0 1.5 1.3 |
325 | 100 | 50 | 166 |
| 100N160 | 72 54 36 |
20 15 10 |
156 165 170 |
2950 | 57.7 51.6 39.7 |
75 | Y280S-2 | 61 60 55 |
1.5 1.4 1.35 |
400 | 100 | 50 | 188 |
| 150N85 | 68 | 18.89 | 86 | 2950 | 33.4 | 44 | Y225M-2 | 48 | 1.35 | 263 | 150 | 100 | 280 |
| 150N85 | 114 | 31.67 | 85 | 2950 | 38.8 | 45 | Y225M-2 | 68 | 1.5 | 263 | 150 | 100 | 280 |
| 150N85 | 137 | 38.06 | 79 | 2950 | 42 | 45 | Y225M-2 | 70 | 2.0 | 263 | 150 | 100 | 280 |
| 150N110 | 80 | 2.2 | 122 | 2950 | 48.3 | 75 | Y280S-2 | 55 | 1.35 | 300 | 1500 | 100 | 190 |
| 150N110 | 100 | 27.8 | 116 | 2950 | 52.6 | 75 | Y280S-2 | 60 | 1.4 | 300 | 150 | 100 | 190 |
| 150N110 | 110 | 30.5 | 112 | 2950 | 55 | 75 | Y280S-2 | 61 | 1.5 | 300 | 150 | 100 | 190 |
| 150N130 | 90 | 25 | 140 | 2950 | 54.5 | 75 | Y280S-2 | 63 | 1.6 | 340 | 150 | 100 | 210 |
| 150N150 | 130 | 36.1 | 124 | 2950 | 73 | 90 | Y280M-2 | 65 | 1.6 | 360 | 150 | 100 | 235 |
| 150N180 | 80 | 22.2 | 150 | 2950 | 73 | 90 | Y280M-2 | 51 | 1.6 | 380 | 150 | 100 | 266 |
| 200N32 | 370 | 102.8 | 32 | 1480 | 38.9 | 55 | Y250M-4 | 83 | 2 | 315 | 200 | 150 | 285 |
| 200N65 | 120 | 33.33 | 69 | 2950 | 37 | 55 | Y250M-2 | 61 | 1.2 | 255 | 200 | 100 | 298 |
| 200N65 | 162 | 45 | 60 | 2950 | 40.1 | 55 | Y250M-2 | 66 | 1.6 | 255 | 200 | 100 | 198 |
| 200N80 | 98 | 27.2 | 90 | 2950 | 40.0 | 75 | Y280S-2 | 60 | 1.10 | 256 | 200 | 100 | |
| 200N80 | 150 | 41.7 | 87 | 2950 | 48.4 | 75 | Y280S-2 | 73.5 | 1.25 | 256 | 200 | 100 | |
| 200N80 | 185 | 51.4 | 82 | 2950 | 54.4 | 75 | Y280S-2 | 76 | 1.35 | 256 | 200 | 100 | |
| 200N80 | 198 | 55 | 80 | 2950 | 57.5 | 75 | Y280S-2 | 75 | 1.50 | 256 | 200 | 100 | |
| 150N110 | 80 100 110 |
22.2 27.8 30.6 |
122 116 112 |
2980 | 48.3 52.7 55 |
75 | Y280S-2 | 55 60 61 |
1.35 1.4 1.5 |
300 | 150 | 188 | |
| 100N130 | 42 52.5 70 |
11.7 14.6 19.4 |
143 141 135 |
2980 | 36 40 46.8 |
55 | Y250M-2 | 44 49 55 |
1.3 1.5 2 |
325 | 100 | 166 | |
