Femoral Condyles Components Fatigue Performance Tester
Производитель: Шанхайская компания Qianshi Precision Electromechanical Technology Co., Ltd
Все товары поставщика
Все товары поставщика
Standard
- ASTM WK51649: Specifies fatigue testing protocols for metallic femoral components in total knee arthroplasty, including F-N curve generation and 10⁷-cycle endurance verification.
- ISO 14879-1: Additional compliance for fatigue testing of total knee joint prostheses.
- Adaptive Protocols: Customizable for emerging standards in additive-manufactured and coated implant evaluation.
Product Advantages
- Ultra-Precision Loading: Electromagnetic actuator delivers ±0.05% force accuracy with 0.001N resolution.
- 10 Million Cycle Endurance: Proven capability to complete ASTM WK51649’s 10⁷-cycle fatigue test without calibration drift.
- Dynamic Load Control: Advanced closed-loop system maintains specified stress ratios during sinusoidal/random loading.
- Real-Time Fracture Detection: AI-powered acoustic emission monitoring identifies micro-cracks at sub-millisecond intervals.
- Intuitive Workflow: 21.5” capacitive touchscreen with gesture control and pre-loaded SOPs for 10+ implant geometries.
- Modular Environmental Chambers: Quick-swap pods for simulated physiological (-20°C to +50°C) and corrosive environment testing.
Product Features
- Electromagnetic Actuator: 5,000 N peak force capacity with programmable load ratios (R=0.1–10).
- Triaxial Loading System: Simultaneous axial/torsional/shear loading (30 Nm max torque).
- Dynamic Load Control: 0.1–30 Hz frequency range with programmable waveforms (sine, square, random, custom).
- Thermal-Mechanical Chamber: ±0.3°C temperature stability with integrated humidity control (10–95% RH).
- High-Speed Imaging Ready: Syncs with external cameras for full-field strain mapping (DIC optional upgrade).
- Safety First: Triple-redundant emergency stop, overload clutches, and laser-based specimen breakage detection.
Technical Parameters
| Parameter | Specification |
|---|---|
| Max. Dynamic Force | ±5,000 N (10,000 N peak optional) |
| Frequency Range | 0.1–30 Hz (0.01 Hz increments) |
| Load Ratio (R) | 0.1–10 (adjustable) |
| Axial Displacement | ±20 mm (0.1 μm resolution) |
| Torque Capacity | ±30 Nm (0.01 Nm resolution) |
| Temperature Range | -20°C to +50°C (environmental chamber) |
| Humidity Control | 10–95% RH (non-condensing) |
| Data Sampling Rate | 100 kHz (synchronized across 16 channels) |
| Power Requirements | 220V/110V ±10%, 50/60Hz, 2,500W |
| Dimensions (W×D×H) | 1,600 × 1,100 × 2,100 mm |
| Weight | 850 kg (including environmental chamber) |
| Noise Level | <68 dB (A-weighted) |
Accessories
- Femoral Condyle Test Fixture Kit:
- Self-centering collet system (28–40 mm femoral component compatibility)
- Laser-aligned loading anvils with diamond-like carbon (DLC) coating
- Thermal-Mechanical Chamber:
- 20L capacity with rapid cooling/heating (15°C/min)
- 316L stainless steel interior with HEPA filtration
- TestMaster Ultimate Software:
- Automated F-N curve generation and fatigue limit calculation
- 21 CFR Part 11-compliant audit trail with blockchain timestamping
- Remote monitoring via dedicated iOS/Android app
- Operator Kit:
- Calibrated torque wrench set (0.5–50 Nm)
- Specimen alignment gauges (ASTM WK51649 compliant)
- Calibration Bundle:
- NIST-traceable force calibration weights
- Temperature/humidity verification probe
- Safety Kit:
- Laser safety curtains
- Acoustic enclosure with 30 dB noise reduction
