Textile Fiber Composition Analyzer
Standard
- ASTM D276(Standard Test Method for Identification of Fibers in Textiles)
- ISO 1833(Determination of Fiber Content in Textiles)
- AATCC 20A(Fiber Analysis: Qualitative)
- GB/T 2910(China National Standard for Quantitative Fiber Analysis)
Product Advantages
- Unparalleled Accuracy
- Advanced spectroscopic technology identifies and quantifies fibers (e.g., cotton, polyester, wool, nylon) with ±0.5% accuracy, even in blended fabrics.
- Rapid Results
- High-speed analysis completes tests in 60 seconds, accelerating production workflows and reducing delays.
- User-Friendly Interface
- 8-inch capacitive touchscreen with intuitive workflow guidance and multilingual support (English, Spanish, French, Korean).
- Durability for Industrial Use
- Robust aluminum alloy housing and anti-vibration design ensure stability in busy laboratory environments.
- Cost-Efficient Operation
- Low reagent consumption and modular components minimize maintenance costs over the product lifecycle.
Product Features
- Multi-Mode Analysis:
- Supportsquantitative(chemical dissolution) andqualitative(microscopic/spectroscopic) testing for comprehensive fiber characterization.
- Automatic calibration for cotton, polyester, and wool blends, with customizable settings for specialty fibers.
- Safety & Compliance:
- Fume extraction system, chemical-resistant casing, and CE/ETL certification for safe handling of hazardous reagents.
- Data Management:
- Cloud-compatible software stores unlimited test results, generates ISO-compliant reports, and supports barcode scanning for sample tracking.
- Universal Sample Compatibility:
- Accommodates fibers, yarns, and fabrics up to 50g in weight, including delicate materials like silk and cashmere.
Technical Parameters
| Parameter | Specification |
|---|---|
| Fiber Identification Range | Natural, synthetic, and blended fibers (cotton, polyester, wool, nylon, acrylic, etc.) |
| Measurement Accuracy | ±0.5% (quantitative), ±98% (qualitative) |
| Test Time | 60–180 seconds (variable by method) |
| Sample Weight Range | 0.1–50g |
| Spectral Resolution | 1 nm (FTIR mode) |
| Power Supply | 100–240V AC, 50/60Hz, 200W |
| Dimensions (L×W×H) | 500×400×600 mm |
| Weight | 60 kg |
| Operating Environment | 15–30°C, ≤70% RH (non-condensing) |
Accessories Included
- Reagent Kit: Chemicals for cotton, polyester, and wool dissolution (ISO-compliant).
- Microscope Slide Set: Pre-cleaned slides for qualitative fiber examination.
- Sample Cutter: Precision tool for uniform fabric sampling (10mm² area).
- Calibration Standards: Certified fiber blends for annual verification.
- User Manual & Software: Digital guide (multilingual) + cloud-based analytics platform for remote data access.
