Powder Wet Vibrating Screen System For Lithium Battery Material Testing
tandard
- ASTM E11: Standard Specification for Woven Wire Test Sieve Cloth and Test Sieves
- ISO 3310-1: Test Sieves – Technical Requirements and Testing – Part 1: Test Sieves of Metal Wire Cloth
- IEC 62660-3: Secondary Lithium-Ion Cells – Part 3: Safety Requirements
- RoHS Compliance(Restriction of Hazardous Substances)
- CE Certification(Conformité Européenne)
Product Advantages
- Wet Sieving Precision
- Sub-10 μm Resolution: Separates nano-scale particles in slurries with 99.5% accuracy.
- Anti-Clogging Design: Ultrasonic transducer prevents particle aggregation during wet testing.
- Corrosion Resistance
- 316L Stainless Steel Construction: Withstands acidic/alkaline electrolytes and organic solvents.
- IP67 Rating: Fully submersible for easy decontamination.
- High-Throughput Processing
- 4-Layer Sieve Stack: Simultaneous particle size distribution (PSD) analysis in 5 minutes.
- Auto-Flush System: Integrates with CIP (Clean-In-Place) protocols for rapid turnover.
- Intelligent Control
- 7” HD Touchscreen: Preprogrammed ASTM/ISO test protocols with customizable dwell times.
- Data Integrity: Blockchain-secured results for audit-ready compliance.
- Safety First
- Explosion-Proof Motor: ATEX-certified for use in inert atmospheres.
- Emergency Drain: Solvent-resistant siphon system with gravity-activated cutoff.
Product Features
- Variable Frequency Drive: Adjustable vibration (50–3,000 RPM) for optimal particle stratification.
- Laser-Guided Leveling: Ensures consistent sieve stack alignment (±0.05° accuracy).
- Temperature Control: Built-in Peltier module (-10°C to 60°C ±0.2°C stability).
- 3D Particle Imaging: Optional microscope adapter for real-time morphology analysis.
- Voice-Activated Controls: Hands-free operation during solvent-intensive tests.
Technical Parameters
| Parameter | Specification |
|---|---|
| Sieve Diameter | 200mm, 300mm, 450mm (interchangeable) |
| Mesh Range | 5 μm – 5 mm (ASTM E11 compliant) |
| Vibration Amplitude | 0.5–3.0 mm (adjustable) |
| Power Supply | 100-240V AC, 50/60Hz (universal adapter) |
| Noise Level | <65 dB (A-weighted) |
| Dimensions | 500mm (W) × 450mm (D) × 800mm (H) |
| Weight | 85 kg (net) / 105 kg (gross) |
Accessories Included
- Sieve Kit:
- 4x stainless steel test sieves (200mm diameter, 20/50/100/200 μm meshes).
- Sieve pan and lid with O-ring seals.
- Software Suite:
- License key forSieveMaster Pro(Windows/macOS).
- 1-year free access to cloud-based PSD analytics.
- Safety & Maintenance:
- Explosion-proof gloves (Class 00, 3 pairs).
- Sieve cleaning brush (stainless steel bristles).
- Wet Testing Kit:
- Solvent-resistant pump (10 L/min flow rate).
- 5m silicone tubing with quick-release fittings.
- Documentation:
- Multilingual quick-start guide (printed + digital).
- Compliance certificates for ASTM/ISO/IEC standards.
