UV Test Chamber
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Features and Benefits
1. STD UV-SI-260 is widely used in UV aging test, which can realize the comprehensive test of UV, temperature, humidity and water.
2. The uv aging test equipment is equipped with 8 UV lamps, and the current of the lamps can be displayed, mainly to display the service life of the lamps, which is convenient for users to replace the lamps in time.UVA-340.UVB-313.UVB-351 are all supported.UV lamp power is 40W.
3. The specimens of the uv aging machine are easy to install, and 52 pieces of 75*150mm specimens can be put in at one time.Customized sample holder is also designed for irregular test pieces.
4. All uv weathering test chambers are CE and RoHS certified.
Specifications
|
Model |
STD UV-SI-260 |
|
Internal Dimension (mm) |
450*1170*500 |
|
Overall Dimension (mm) |
610*1330*1470 |
|
Specimen Holder Size(mm) |
75*150 |
|
Specimen Capacity |
56 Pieces |
|
Irradiation Source |
Fluorescent UV lamps (8) - 40 W |
|
Temperature Range |
Ambient ～ 90 ℃ ±2℃ |
|
Black Panel Temperature (BPT) |
35 ～ 80 ℃ |
|
Humidity Range |
≥95% RH |
|
Bandwidth |
290 ~ 400nm |
|
Irradiance Control |
0.3~20 W/㎡ |
|
Water Spray Cycle |
1~9999H59M (Adjustable) |
|
Distance of Specimen and lamp |
50mm |
|
Controller |
Programmable color LCD touch screen controller, Ethernet connection |
|
Water Supply System |
Automatic water supply, Water purification system |
|
Safety Device |
Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection; Phase Sequence Protection |
|
Exterior Material |
Steel Plate with protective coating |
|
Interior Material |
SUS304 stainless steel |
