UV Xenon Arc Weather Testing Chamber
Product introduction
This equipment uses xenon arc lamp that can simulate the whole spectrum of sunlight reproduction under different environments the destructive wave,which can provide the corresponding simulation environment and accelerated test for scientific research, product development and quality control.Aging test of xenon arc lamp under light and heat radiation by exposing material samples. To evaluate the light and weather resistance of some materials under the action of high temperature light sources. It is mainly used in automobiles, coatings, rubber, plastics, pigments, adhesives, fabrics and so on.
Detailed specification parameters
| Product mix | Sigal box vertical | |||||
|
Technical parameters of xenon lamp |
Temperature rang | RT℃～+80℃ | Light irradiance | |||
| Spectral wavelengths: 290nm～800nm Irradiance range: 550W～1200W/㎡ | ||||||
| Temperature fluctuation | ≤±0.5℃ | |||||
| Temperature uniformity | ≤2℃ | |||||
| cooling rate | 0.7～1℃/min(Nonlinearity) | |||||
| Heating rate | 3～5℃/min(Nonlinearity) | |||||
| Humidity rang | 30%～98%R.H | |||||
| Humidity fluctuation |
3%～4%R.H |
|||||
| Blackboard temperature | 63+3℃ | |||||
|
Test standards for satisfaction |
SAEJ-1885 ；SAEJ-1996 ISO 105B-06 ；ISO 105B-02 ；ISO 105B-04 ISO4892-2 ；ISO11341 AATCC16E ；AATCC169(1) JASOM346-93 GMW3414TM Ford Interior ASTM G155-1 ASTM G155-4 |
|||||
|
Implementation and compliance with standard instructions |
1.ISO 4892-2:2006 2.ISO 11507 3.ASTM G154 |
|||||
|
Texture of material |
Material and size of outer box |
High quality cold rolled steel plate lacquer Deep:1400 wide:1450 high:1950mm |
||||
| Material and size of inner box |
Imported SUS304 stainless steel deep :800 wide: 800 high :800mm |
|||||
| Insulation material | High quality polyamine foamed 100mm | |||||
|
Xenon Lamp House |
Water cooled xenon lamp | 6kw, More than 1200 hours of life, easy to disassemble | ||||
| Light irradiance | deviation | ±0.01W/m2 | ||||
| High radiation intensity control | It can reach 2 sun or higher levels | |||||
| Comparison of the spectrum of xenon lamp artificial climate test box light with the sun | ||||||
|
Sprinkler and water source |
1. water pressure: 138 ~ 344Kpa (20 ~ 50psi); flow: minimum 0.6L/min. 2. xenon lamp cooling, spray, humidification water use water: required to reach the national analytical laboratory two level water quality, water solid impurity content less than 1mg/L. 3. The sewerage of the test box is located at the left rear of the bottom of the box. 4. The temperature of the environment is 23±2℃, and the relative humidity is less than 80%. It should not be installed and used in the corrosive, toxic and harmful environment. |
|||||
|
Heating system |
heater | Stainless steel ,316L fins, heat dissipating tube electric heater, Control mode: PID control mode, using non contactless periodic pulse width modulation SSR (solid state relay) | ||||
|
Controller |
Essential information | TEMI-990 Truecolor touch programmable temperature and humidity controller | ||||
| The program controls 30 sets of 100 segments (the number of segments can be arbitrarily adjusted to each group) | ||||||
| R232 communication interface | ||||||
| Operation mode | Fixed value / program | |||||
| Setting method | Manual input | |||||
| Set range | Temperature: -199℃～+200℃ | |||||
| Humidity: 0% to 100% | ||||||
| Time:0~9999 hours / minutes / seconds | ||||||
| Resolving power | Temperature: 0.01℃ | |||||
| Humidity: 0.01% | ||||||
| Time:0.1s | ||||||
| Input | PT100 platinum resistance | |||||
| Ancillary function | Alarm display function (prompting the cause of failure) | |||||
| Upper and lower limit temperature alarm function | ||||||
| Timing function, self diagnostic function | ||||||
| Measurement data acquisition | PT100 platinum resistance | |||||
|
Component configuration |
refrigeration system | Compressor | French original "Tai Kang" full closed compressor unit | |||
| Refrigeration mode | Single stage refrigeration | |||||
| Refrigerant | Environment-friendly R-404A | |||||
| Filter | ||||||
| Condenser | Taiwan middle force | |||||
| Evaporator | ||||||
| expansion valve | Danish original "Danfoss" | |||||
| Air supply circulation system | The forced circulation of air by a stainless steel fan | |||||
| Chinese foreign joint venture "constant profit" differential motor | ||||||
| Multi wing wind turbine | ||||||
| Air supply system as a single cycle | ||||||
| Window light | Philips | |||||
| Other configuration | Stainless steel movable sample frame can be moved 1 layers | |||||
| Hollow conductive thermal defrosting functional glass observation window and light lamp | ||||||
| Universal moving wheel angle | ||||||
|
Safeguard |
Xenon lamp cooling water shortage protection | |||||
| Low (high) alarm of xenon lamp irradiance | ||||||
| Door safety protection | ||||||
| Production standards | GB/2423.1 ；GB/2423.2；GB/2423.3.GB/2423.4 | |||||
|
Conditions of use |
Power |
A380V; Allowable range of voltage fluctuation: AC380V ± 10% Frequency allowable fluctuation range: 50Hz ±0.5 Hz Protection ground wire grounding resistance less than 4 omega; TN-S mode power supply or TT mode power supply |
||||
| Use of the environment |
Temperature: 5℃～35℃ relative humidity: ≤85%RH |
|||||
| Space |
The ground is smooth and well ventilated, without inflammable, explosive and corrosive gases and dust There is no strong electromagnetic radiation source nearby There is a proper maintenance space around the equipment |
|||||
Features
1.Presetting various specifications, Custom program capability, meet diverse range of standards, including AATCC, ISO, BS, JIS etc.
2.Automatic compensating system (PATENT) control the Xenon Lamp Power.
3.Colorful touch screen, indicate the condition of chamber at real-time, be able to presetting irradiance, temperature (BPT, BST, chamber), humidity, and plot dynamic curve of them. The operator simply selects the required test module and test standards; English user interface, diagram indicate condition of chamber, easy to use.
4.PLC control, powerful program and storage property, save the parameters when interrupt of power supply.
5.Chamber temperature control, irradiation temperature, and heater raise the temperature, air conditioning refrigeration.
6.Irradiation control, light irradiance sensor monitor, digital setting, automatic compensating system, stepless adjustable.
7.Sample holder/ rack:360 degree rotating, can hold samples of different sizes.
8.Xenon Arc Lamp to simulate the best full spectrum sunlight.
